TLC Series
TOP
Features:
Microcomputer digital control, real-time display of temperature and humidity, display accuracy of 0.1C
The temperature inside the box is controlled within the range of 8 ° C to 20 ° C.
Multiple fault alarms: high and low temperature alarm, humidity alarm, sensor fault alarm, etc
A shelf with label strips, convenient for users to identify and store drugs, reagents, etc.
Built in lighting, high brightness and energy-saving, making it easy to see the drugs and reagents inside the cabinet at a glance.
Features:
Microcomputer digital control, real-time display of temperature and humidity, display accuracy of 0.1C
The temperature inside the box is controlled within the range of 8 ° C to 20 ° C.
Multiple fault alarms: high and low temperature alarm, humidity alarm, sensor fault alarm, etc
A shelf with label strips, convenient for users to identify and store drugs, reagents, etc.
Built in lighting, high brightness and energy-saving, making it easy to see the drugs and reagents inside the cabinet at a glance.
Technical data
Model | TLC-L288 | TLC-L388 | TLC-L668 | TLC-L868 | TLC-L1008 |
Volume (L) | 288 | 388 | 668 | 868 | 1008 |
Temperature range (°C) | 8 ~ 20 | ||||
Rated voltage/frequency (V/Hz) | 220/50 | ||||
Rated power (W) | 280 | 300 | 400 | 450 | 480 |
Power consumption (KWh/24h) | 3.0 | 3.5 | 4.6 | 5.0 | 5.2 |
Types of electrocution protection | I | ||||
Climate type | N | ||||
Net weight (kg) | 94 | 107 | 155 | 178 | 194 |
Noise (dBA) | 52 | 52 | 55 | 55 | 52 |
Insulation layer Thickness (mm) | 40 | 40 | 60 | 60 | 60 |
Placed on the web/board (layer) | 5 | 5 | 5 | 5 | 5 |
Product dimensions (mm) | 605*675*1610 | 605*675*1925 | 1220*625*1885 | 1220 * 755 * 1885 | 1220*855*1885 |
Inner box dimensions (mm) | 525*575*1050 | 525*575*1366 | 1100*504*1325 | 1100*634*1325 | 1100*734*1325 |
Packaging Material (Conventional) | Wooden pallet + carton | ||||
Packaging dimensions mm (regular) | 685*765*1705 | 685*765*2025 | 1300*705*1985 | 1300*835*1985 | 1300*940*1985 |
Packaging material 2 | Plywood | ||||
Packaging size 2 (mm) | 695*775*1760 | 695*775*2075 | 1310*715*2035 | 1310*845*2035 | 1310*950*2035 |
Structure | Lower-mounted unit | Lower-mounted unit | Bottom-mounted unit | Bottom-mounted unit | Bottom-mounted unit |
Certificate |
Product configuration
Style | Vertical | Roller form | Self-locking universal rubber rollers | ||
Color | Milky white | Cabinet lighting lamp | LED | Put on the net | Plastic dipping |
Cooling method | Air cooling | Thermostat | Microcomputer LED digital display temperature controller | Door | Plastic profile frame double-layer hollow glass door |
Thermal insulation materials | Pentamethylene polyurethane foam insulation layer | Hold hands | Embedded handle | ||
Evaporator | Blow-up evaporator | Refrigerant | R134a | Door seal strip | Rubber band airbag door seal |
Condenser | Tube condenser | Outer box, inner box materials | Cold rolled steel sheets, electrostatic spraying | Alarm method | Bee buzzing sound and flashing display alarm |
Lock | Alloy Industrial Cabinet Lock | Alarm function | High and low temperature alarms, sensor malfunction alarms. | ||
Optional configuration | Remote monitoring / USB data interface / Temperature recorder |
