Total magnification 40X–640X, 40X–1000X, 40X–1600X with monocular, binocular, or trinocular observation tube, 30°–45° inclined, 360° rotatable
WF10X/18mm eyepiece, optional H12.5X/12.5mm or H16X/10mm
Achromatic objectives: 4X, 10X, 40X(Spring), 100X(Spring, Oil)
Double-layer mechanical stage, 115×125mm, moving range 76×52mm, with slice clips
Coarse and fine focusing on different axes, coarse range 20mm, fine graduation 1.3mm
Abbe condenser NA1.25 with iris diaphragm, lever lift; high-brightness LED bottom light, brightness adjustable
Built-in 18650 rechargeable battery (1600 mAh), external AC100-240V adapter, optional CCD camera interface


Total magnification 40X–1000X with binocular or trinocular tube, 30° inclined, 360° rotatable
WF10X/18mm eyepiece with PH Infinity Achromatic objectives: 4X, 10X, 40X(Spring), 100X(Spring, oil)
Curved double-layer mechanical stage, 140×140mm, stroke 76×52mm, with slice clips
Coaxial coarse and fine focusing, adjustable elasticity, coarse stroke 28mm, fine accuracy 0.002mm
Illumination: USB flexible upper light, 3W LED bottom light, brightness and color temperature adjustable, compound eye lighting
Condenser: Abbe NA1.25, iris diaphragm, center adjustable, handwheel lifting; critical Kohler illumination
Intelligent sensing device with 30-minute auto shutdown, LED smart display, optional 0.5X C-type camera interface


Total magnification 40X–1600X with compensation binocular or trinocular tube, 30° inclined, 360° rotatable, interpupillary distance 48–75mm
WF10X/20mm and WF16X/10mm wide-field eyepieces
195N Achromatic objectives: 4X, 10X, 40X(Spring), 100X(Spring, oil)
Coaxial coarse and fine focusing, coarse stroke 22mm, fine graduation 0.001mm, elasticity adjustable, upper limit adjustable, random positioning
Homothermal stage, temperature range: room temperature to 50℃, control accuracy ≤±1℃, heating power 12V
Illumination: upper 1W LED optional, bottom 3W LED standard, precision stepless dimming, no flicker
Condenser: Abbe N.A=1.25, iris diaphragm, center adjustable, lift up/down; optional C-type camera interfaces 0.5X, 0.65X, 1X


Total magnification 40X–1600X with high eyepoint wide-field eyepiece WF10X/20mm or WF16X/16mm, diopter adjustable
Infinity Plan High Contrast Achromatic objectives: 4X, 10X, 40X(Spring), 100X(Spring, oil)
Double-layer mechanical sliding stage 188×145mm, moving range 76×54mm, triangle steel column guide, two double slide clips
Coaxial coarse and fine focusing, coarse stroke 22mm, fine accuracy 0.001mm, adjustable elasticity and upper limit, random positioning
Illumination: upper 1W LED optional, bottom 3W LED standard, halogen 6V/30W optional, full Kohler illumination, precise stepless dimming
Condenser: Full Kohler Abbe condenser N.A=1.25, lift up/down, center adjustable, iris diaphragm
Optional attachments: dark field, phase contrast, fluorescence, polarized accessories; C-type camera interface 0.5X/0.65X/1X


Total magnification 40X–1000X with WF10X/18mm eyepiece, optional WF16X/15mm or WF20X
Achromatic objectives: 4X, 10X, 40X (spring), 100X (spring, oil)
Observation tube options: monocular 45° inclined, or binocular/trinocular 30° inclined, 360° rotatable
Double-layer mechanical stage 120×115mm, stroke 76×40mm, with Abbe condenser NA 1.25 and iris diaphragm
Coaxial coarse and fine focusing system, coarse stroke 28mm, fine accuracy 0.002mm, tightness adjustable
Illumination system: LED 1W/3W, non-rechargeable, brightness adjustable, reflector accessory optional
Digital circuit dimming with precise stepless adjustment, no flicker, power supply AC90–240V input, DC 5V/2A output


Total magnification range 40X–1600X with wide-field WF10X/18mm, WF16X/11mm or Huygens eyepieces
Achromatic objectives: 4X, 10X, 40X (spring), 100X (spring, oil) depending on model
Observation tube options: monocular 45° inclined, 360° rotatable, or binocular tube
Stage options: Φ90mm round stage with 6mm movement, or double-layer mechanical stage 60×30mm
Coarse and fine focusing system, coarse range 10mm, fine accuracy 1.8mm
Illumination: high-brightness LED cold light source, rechargeable, adjustable brightness, optional condenser
Durable and portable design with built-in handle, external AC95V–250V power adapter


Total magnification 40X–1600X with wide-field WF10X/18mm and optional WF16X/15mm eyepieces
195mm Achromatic or Plan Achromatic objectives: 4X, 10X, 40X (spring), 100X (spring, oil)
Viewing tube options: monocular, binocular, or trinocular, inclined 30°–45°, 360° rotatable, interpupillary 48–75mm
Double-layer mechanical stage 115×125mm or 140×132mm, moving range 76×52mm, with dual slide clips
Coaxial coarse & fine focusing, coarse range 22mm, fine accuracy 0.002mm, tension control
Illumination: 3W LED adjustable bottom light, optional 1W LED upper light, Abbe condenser N.A.=1.25 with iris diaphragm
Power supply: DC6V/2A external adapter, optional CCD/Camera adapters & accessories available


Adjustable trinocular viewing tube, 30° inclined, 360° rotatable, interpupillary distance 48–75mm
Wide-field eyepiece WF10X/20mm, optional WF16X/15mm, diopter adjustable
Infinity objectives: 4X, 10X, 40X (spring), 100X (spring, oil) with high clarity imaging
Double-layer mechanical stage 160×142mm, moving range 76×52mm, with dual clips
Coaxial coarse & fine focusing system, coarse 22mm, fine adjustment 0.002mm, with tension control
Illumination: 3W LED compound eye bottom light (adjustable), optional 1W LED upper light or 12V/20W halogen lamp
Abbe condenser N.A.=1.25, adjustable with iris diaphragm, compatible with camera adapters & optional accessories


Mechanical tube length 160mm with monocular vertical observation tube
Achromatic objectives: 4X, 10X, 40X spring, 100X spring oil; Huygens eyepieces H5X, H10X, H16X
Metal single-layer square stage 120×120mm with slice clips and moving ruler, anti-corrosion
Focusing system: refined metal rack and pinion, coarse range 50mm/20mm, fine adjustment 1.8–2.2mm, focusing limit mechanism
Illumination: Plano-concave mirror Φ50mm, optional LED 1W or incandescent 20W light source
Abbe condenser N.A.=1.25 with iris diaphragm and filter holder
Sturdy metal horseshoe base, arm bracket tilt 45°, durable and stable


Optical System: Infinity achromatic correction, 45mm focal length, open field observation
Magnification: 40X–1000X with achromatic, plan achromatic, or infinity plan achromatic objectives (4X, 10X, 40X spring, 100X spring oil)
Eyepiece: Wide field WF10X/20mm, optional WF16X/15mm, teaching pointer optional
Stage: Double-layer mechanical stage, 160×142mm, moving range 76×52mm, with double slide clips and anti-extrusion function
Focusing: Coaxial coarse/fine, coarse stroke 22–25mm, fine adjustment 0.001mm, elasticity adjustable
Illumination: Bottom 3W LED cold light, precise stepless dimming, upper optional 1W LED, lifespan ≥50,000h
Camera Interface: C-type 0.5X/0.65X/1X optional, external AC90–240V power supply, NMPA & CE certified
