Sample capacity: 8×0.2 mL (8-well block)
Reaction volume: 15–100 µL
Temperature range: 0–100℃, ramp rate 7℃/s, ±0.25℃ accuracy
Detection: High-sensitivity photodetector, long-life LED excitation
Excitation/Emission channels: FAM/SYBR, HEX/VIC, ROX, CY5 (depending on model)
Features: Quantitative/qualitative analysis, portable, field-ready with optional lithium battery
Connectivity & Power: Wi-Fi/USB2.0, compact 3 kg, forward/backward vent design


Sample capacity: 8×0.2 mL (8-well block)
Reaction volume: 15–100 µL
Temperature range: 0–100℃, ramp rate 7℃/s, ±0.25℃ accuracy
Detection: High-sensitivity photodetector, long-life LED excitation
Excitation/Emission channels: FAM/SYBR, HEX/VIC, ROX, CY (depending on model)
Features: Quantitative/qualitative analysis, melting curve, genotyping
Connectivity & Power: Wi-Fi/USB2.0, optional lithium battery, compact 3 kg


Dual channels with double 8-well blocks, can run two programs simultaneously
Temperature range 0–100°C, resolution 0.1°C, uniformity ±0.25°C, fluctuation ±0.1°C
Reaction volume 10–100 μL, compatible with 0.2 mL PCR tubes and 8-tube strips
7-inch TFT color touch screen with Win10 OS, optional USB printer, 20GB memory stores up to 40,000 experiments
High sensitivity side-scanning photoelectric detector, long-life LED excitation, supports FAM/SYBR, HEX/VIC, ROX, CY5 dyes
Dynamic range 1–10¹⁰ copies, detection sensitivity down to 1 copy, supports quantitative, qualitative, melting curve, genotyping analysis
Compact and portable (300×267×198 mm, 8 kg), forward/backward air vents, supports battery power for field testing


Four channels with dual 16-well blocks, can run two programs simultaneously
Temperature range: 0–100°C, resolution 0.1°C, uniformity ±0.25°C, fluctuation ±0.1°C
Reaction volume: 10–100 μL, compatible with 0.2 mL PCR tubes and 8-tube strips
7-inch TFT color touch screen with Win10 OS, optional USB thermal printer, 20GB flash memory for 40,000 experiments
High sensitivity side-scanning photoelectric detector, long-life LED excitation, supports FAM/SYBR, HEX/VIC, ROX, CY5 dyes
Dynamic range: 1–10¹⁰ copies, detection sensitivity down to 1 copy, supports quantitative, qualitative, melting curve, genotyping analysis
Compact design (300×267×198 mm), lightweight 8kg, forward/backward air vents, DC15V 255W, voltage 220V 50Hz


Sample Capacity: 16×0.2 mL (2×8-well double block), reaction volume 10–100 µL, supports clear 0.2 mL tubes or 8-tube strips
Temperature Control: Marlow Peltier module, 0–100°C, max ramp rate 6°C/s, uniformity ±0.25°C, accuracy ±0.25°C, hot lid 30–115°C adjustable
Detection & Optics: High-sensitivity photoelectric detector, LED excitation, emission F1: 520–540 nm, F2: 540–580 nm, supports FAM/SYBR Green, HEX/VIC/JOE/TET dyes
Interface & Software: 7-inch HD TFT color touch screen (1280×800), Windows 10 OS, quantitative/qualitative analysis, melting curve, genotyping, 20 GB flash memory, optional USB thermal printer
Connectivity & Power: WiFi/USB2.0, DC 15V 250W, compact size 300×267×198 mm, weight 8 kg, supports battery operation for field testing
Features: Dual-channel independent operation, side scan technology, black reaction block for low background, forward/backward air vents, automatic recovery after power-off, electromagnetic lock cover


Sample throughput: 1
Sample tube: 0.5 ml PCR tube (thin-walled tube)
Sample volume: 1~20μL
Processing speed：3s
Data output: USB/Wifi
Excitation filter: Blue 460~480nm Red 630~650nm
Emission filter: Green 500~535nm Red 670~710nm


Sample capacity: 96x0.1ml PCR tube / 12x0.1ml 8-strip tube / 96-well microplate
Reaction volume: 10~50μL
Excitation/detection range: 415~685nm / 455~745nm
Temp setting range: 4~100℃
Gradient zone: 12 columns
Fluorescence channel: 4 / 6 (depend on models)
Dye compatibility:
F1: FAM/SYBR GreenI
F2: VIC/HEX/TET/JOE/TAMRA
F3: ROX/Texas Red
F4: Cy5/LIZ
F5: Quasar705/Alexa Fluor 680/Cy5.5
F6: ATT0425


Sample capacity: 16×0.2mL PCR tube / 2×0.2mL strip tube
Reaction volume: 10~50μL
Block Temp control range: 10~100°C
Hot lid temp control range: 30~105°C
Display: 7-inch color touch screen
Fluorescence channel: FAM/SYBR,VIC/HEX/TET or FAM/SYBR,VIC/HEX/TET,ROX,CY5/TAMRA
