Ultra-Low Temperature Freezers (ULT Freezers)
You are here: home » Products » Refrigerator & Freezers » Ultra-Low Temperature Freezers (ULT Freezers)

Product Category

Ultra-Low Temperature Freezers (ULT Freezers)

Ultra-Low Temperature Freezers (ULT Freezers) are specialized cold storage units designed to maintain temperatures between -40°C and -86°C, providing optimal long-term preservation of biological samples, vaccines, enzymes, tissue, DNA/RNA, and other sensitive materials. These freezers are essential in biobanks, pharmaceutical labs, hospitals, and research facilities where temperature precision and sample integrity are critical.


Our ULT freezers deliver uniform ultra-low temperatures with advanced insulation, microprocessor-based controls, and high-efficiency compressors. They feature safety systems including over-temperature alarms, backup battery monitors, and password-protected access to ensure security and compliance.


Available in upright and chest configurations, our models meet various storage capacity and space requirements. Whether for medical research, life science, or clinical applications, our ultra-low freezers ensure sample stability and regulatory compliance, even in the most demanding laboratory environments.

  • TW-W458 Ultra-Low Temperature Freezer -105℃ 458L Cryogenic Biomedical Freezer for Laboratory and Research
    Capacity: 458L with food-grade 304 stainless steel liner
    Temperature range: -15℃ to -105℃ (model dependent)
    Temperature control: Microcomputer digital control with 0.1℃ accuracy, LED real-time display
    Security system: Multi-alarm protection (high/low temp, sensor failure, password lock) with sound & light alerts
    Cooling system: Imported compressor, cascade refrigeration, eco-friendly refrigerant, low-noise German EBM fan
    Design: Adjustable stainless steel shelves, caster wheels, safety door lock, USB data recording (optional)
    Power: 220V/50Hz, 500W–900W, Net weight 207–216kg

    Model: TW-W458 Series
    Add to Basket
  • TW-W258 Ultra-Low Temperature Freezer -135℃ 258L Biomedical Cryogenic Freezer for Laboratory & Research
    Capacity: 258L with food-grade 304 stainless steel liner
    Temperature range: -15℃ to -135℃ (model dependent)
    Temperature control: Microcomputer digital control, 0.1℃ adjustment, LED real-time display
    Security system: Multi-alarm protection (high/low temp, sensor failure, power issue) with sound & light alerts
    Cooling system: Imported compressor, eco-friendly refrigerant, cascade refrigeration, low noise German EBM fan
    Design: Adjustable stainless steel shelves, caster wheels, safety door lock, USB data recording (optional)
    Power: 220V/50Hz, 350W–1150W, Net weight 162–171kg

    Model: TW-W258 Series
    Add to Basket
  • TW-L58 Ultra-Low Temperature Freezer -86℃ 58L Biomedical Cryogenic Freezer for Laboratory & Research
    Capacity: 58L compact chamber with stainless steel liner
    Temperature range: -15℃ to -86℃ (model dependent)
    Temperature control: Microcomputer digital control, 0.1℃ adjustment, LED display
    Security system: Multiple alarms (high/low temp, sensor failure, power issue) with sound & light alerts
    Cooling system: Imported compressor, eco-friendly refrigerant, optimized cascade refrigeration
    Design: Adjustable stainless steel shelves, caster wheels, safety door lock, USB data recording (optional)
    Power: 220V/50Hz, 350W–380W, Net weight 83kg

    Model: TW-W58 Series
    Add to Basket
  • TW-L938 Ultra-Low Temperature Freezer -86℃ 938L Biomedical Cryogenic Storage for Laboratory & Research
    Capacity: 938L large storage chamber
    Temperature range: -15℃ to -86℃ (model dependent)
    Temperature control: Microcomputer digital display, adjustable to 0.1℃
    Security system: Multiple alarms (high/low temp, power failure, sensor error) with sound & light alerts
    Cooling system: Imported compressor, eco-friendly refrigerant, optimized cascade refrigeration
    Interior: Food-grade 304 stainless steel liner with adjustable shelves
    Design: LED display, caster wheels, safety lock, optional USB data recording

    Model: TW-L938 Series
    Add to Basket
  • TW-L508 Series Ultra Low Temperature Freezer -40℃ to -86℃ 508L Large Capacity Laboratory and Medical Freezer
    External dimensions: 870×1030×1975 mm; Internal dimensions: 570×710×1255 mm
    Chamber temperature range: -15~-40℃ (TW-40L508), -25~-60℃ (TW-60L508), -40~-86℃ (TW-86L508)
    Capacity: 508 L; Net weight: 250 kg
    Microcomputer digital control with real-time LED display and 0.1℃ accuracy
    Comprehensive alarm system with sound and light alerts for temperature, sensor, and power failures
    High-efficiency cooling system with imported compressor, eco-friendly refrigerant, and extra-thick insulation
    304 stainless steel inner liner, adjustable shelves, safety lock, universal casters, optional USB data logging

    Model: TW-L508 Series
    Add to Basket
  • TW-L158 Series Ultra Low Temperature Freezer -40℃ to -86℃ 158L Laboratory and Medical Freezer
    External dimensions: 700×700×1580 mm; Internal dimensions: 460×455×800 mm
    Chamber temperature range: -15~-40℃ (TW-40L158), -25~-60℃ (TW-60L158), -40~-86℃ (TW-86L158)
    Capacity: 158 L; Net weight: 123–128 kg
    Microcomputer digital control with 0.1℃ adjustment accuracy and real-time LED display
    Advanced alarm system: high/low temperature, sensor failure, power issues with sound and light alerts
    Efficient cooling system with imported compressor, eco-friendly refrigerant, and extra-thick insulation
    304 stainless steel inner liner, adjustable shelves, safety lock, universal casters, and optional USB data logging

    Model: TW-L158 Series
    Add to Basket
  • TW-L58 Series Ultra Low Temperature Freezer -40℃ to -86℃ Small 58L Laboratory & Medical Freezer
    External dimensions: 540×620×1115 mm (TW-40L58 / TW-60L58), 600×665×1145 mm (TW-86L58); Internal dimensions: 364×405×410 mm
    Chamber temperature range options: -15~-40℃ (TW-40L58), -25~-60℃ (TW-60L58), -40~-86℃ (TW-86L58)
    Capacity: 58 L, Net weight: 73–78 kg
    Microcomputer digital control with LED display, temperature adjustment unit 0.1℃
    Advanced alarm system: high/low temperature, power, and sensor failure with sound and light alerts
    Efficient refrigeration with imported compressor, eco-friendly refrigerant, thick foam insulation, and double-seal door design
    Food-grade 304 stainless steel liner, adjustable shelves, safety door lock, universal casters, optional USB data logging

    Model: TW-L58 Series
    Add to Basket
  • TW-L28 Series Ultra Low Temperature Freezer -40℃ to -86℃ Small Capacity Laboratory & Medical Freezer
    External dimensions: 470×490×1120 mm, Internal dimensions: 270×265×400 mm, Volume: 28 L
    Temperature range options: -15~-40℃ (TW-40L28), -25~-60℃ (TW-60L28), -40~-86℃ (TW-86L28)
    Microcomputer digital control with LED temperature display, adjustment unit 0.1℃
    Advanced security system with high/low temperature, power, and sensor alarms, plus multiple protection functions
    Optimized self-cascade refrigeration system with imported compressor, eco-friendly refrigerant, and low energy consumption
    Food-grade 304 stainless steel liner, adjustable shelves, safety door lock, universal casters for mobility
    Optional digital temperature recorder with USB interface for data logging and analysis

    Model: TW-L28 Series
    Add to Basket
  • Ultra Low Temperature Freezer -40℃ to -86℃ for Biological Sample Storage – Model T-86V340E
    External dimensions: 854×1006×1907 mm, Interior dimensions: 488×607×1140 mm, Volume: 340 L
    Temperature range: -40℃ to -86℃, microprocessor control, LED digital display
    Direct cooling with auto-cascade system, VIP insulation, multi-layer sealing for stable ultra-low temperature
    Alarms: high/low temperature, power failure, sensor error, abnormal voltage, door ajar, condenser clean, low battery
    Storage capacity: 192 boxes (2-inch), 19200 samples (2ml), adjustable SUS304 racks and foamed inner doors
    Energy-efficient, CFC-free refrigerant, power consumption 13.09 kWh/24h, noise level 52 dB
    Optional accessories: chart recorder, data logger, CO2 or LN2 backup system, gloves

    Model: T-86V340E
    Add to Basket
  • Ultra-Low Temperature Freezer –86°C, 188L Upright Laboratory Freezer MDF-86V188E for Biological Sample Storage
    Temperature Range: –40℃ to –86℃ (1℃ increments)
    Capacity: 188L, internal size 465×465×830 mm
    External Dimensions: 830×810×1607.5 mm, Net Weight: 150 kg
    Material: Color sprayed steel exterior, SUS stainless steel interior
    Insulation: High-performance VIP panels + PU foam, unique insulated inner door
    Alarm System: High/low temp, power failure, sensor error, filter inspection, ambient temp alarm

    Model: MDF-86V188E
    Add to Basket
