Shaker Accessories for PK Series
Includes dish trays with non-slip mats in various sizes (24×21.5 cm, 28×28 cm, 30×23 cm, 30×28.5 cm)
Universal attachments and lengthways roller attachments for different shaker models
Fixing clips for 25 mL, 50 mL, 100 mL, 200/250 mL, and 500 mL flasks
Connect sticks for multiple layer shaker configurations
Compatible with PK-O, PK-L, PK-R, and PK-D series shakers
Materials: durable, non-slip, and corrosion-resistant


Max Load Capacity: 7.5 kg (O330) / 2.5 kg (O180)
Shaking Amplitude: 10 mm (O330) / 4 mm (O180)
Speed Range: 100-350 rpm, LCD Display
Timer: 1 min – 19 h 59 min, LCD Display
Motor: Brushless DC, 28W input / 15W output
Dimensions: 370 × 420 × 100 mm (O330) / 300 × 340 × 100 mm (O180), Weight: 13.5 kg / 8.1 kg, RS232 Interface


Max Load Capacity: 2 kg
Amplitude: 20 mm
Speed Range: 40-200 rpm (LED Display)
Timer: 1 min – 99 h 59 min (LED Display)
Motor: Brushless DC, 16W input / 10W output, Maintenance-free
Dimensions: 290 × 348 × 130 mm, Weight: 3.4 kg


Max Load Capacity: 3 kg
Amplitude: 20 mm
Speed Range: 0-200 rpm (Dial Display)
Motor: DC, 16W input / 10W output, Low Maintenance
Dimensions: 270 × 330 × 110 mm, Weight: 3.1 kg
Power Supply: AC 100-240V, 50/60Hz, 20W


Shake models: Convolution, Cyclotron/Reciprocating, Reciprocate
Speed range: 0–300 rpm, high-precision PID control ±1 RPM
Temperature range: Ambient to 100°C, accuracy ±0.1°C, uniformity ≤0.1°C
Platform size: 498×316 mm, max capacity: 100 mL×24 / 250 mL×15 / 500 mL×11 / 1000 mL×6
Programmable control: Multi-step speed, temperature, time; slow-start & stop design
Display: LCD, with memorized parameters, encryption & power outage recovery
Optional features: UV/lighting function, continuous or timed operation


Control: P.I.D microprocessor with precise temperature and speed regulation
Shake Modes: Convolution or Reciprocate; adjustable RPM range 0–450 / 0–600 / 0–260
Platform: One platform, size 450×410 mm or 410×360 mm; max capacity up to 2000 mL × 4
Temperature: ambient +5°C to 65°C, ±0.1°C accuracy, uniformity ≤0.5°C at 37°C
Features: LCD display, programmable temp/speed/time, ultra-low speed start, slow acceleration/deceleration, door protection, alarm system
Power & Size: AC220V, 50Hz, 550W, dimensions 750×710×520 mm, capacity 70 L


Shake Modes: Orbital (Convolution) & Reciprocating, single platform, multi-flask capacity (100 mL–2000 mL)
Temperature Range: 4°C–65°C, high-precision control ±0.1°C, uniformity ≤0.5°C (37°C)
Speed Control: 0–450 / 0–600 / 0–260 rpm (model-dependent), precision ±1 rpm, slow-start/stop design
Display & Control: LCD touch screen, programmable multi-step temp/speed/time, memory & encrypted parameters
Safety & Features: Open-door protection, PID motor control, automatic defrost, audible/visual alarms
Platform Size: 450×410 mm or 410×360 mm; overall capacity 70 L
Power: AC220 V, 650 W, refrigeration included


PID microprocessor-controlled incubator shaker with programmable temperature, speed, and time.
Forced convection for high-precision temperature control (±0.1°C) and uniformity ≤0.5°C.
Multi-mode shaking: orbital (convolution) or reciprocating, with adjustable orbit diameter (Φ26–50 mm).
Maximum capacity: 100 mL×23 to 2000 mL×4; single platform size: 450×410 mm.
LCD touch screen display (7-inch), ultra-low speed start, and slow acceleration/deceleration design.
Safety features: open door stop, overspeed protection, power outage memory, and encrypted parameter storage.
Optional refrigeration version: temperature range 4°C–65°C, continuous or timed operation.


Model: PNYC-100B / PNYC-100D / PNYC-100F, programmable orbital/reciprocating shaker with forced convection
Speed range: 0–450 / 0–600 / 0–260 rpm, accuracy ±1 rpm, multi-step programmable rotation
Temperature range: ambient +5°C to 65°C, PID-controlled, ±0.1°C accuracy, uniformity ±0.5°C at 37°C
Maximum capacity: up to 23×100 mL flasks or 6×1000 mL flasks; single platform design, orbit diameter 26–50 mm
Safety & protection: slow-start/stop, overspeed protection, open-door stop, sound & light alarms, parameter encryption
Control interface: 7-inch touch screen, multi-step temp, speed, time programming, automatic resume after power outage
Additional features: automatic defrost, high-precision air duct design for temperature uniformity, continuously running or timed operation


Oscillation Modes: Rotary, Reciprocating, Rocking, or 3D Motion (model dependent)
Speed Range: 15–240 rpm (Rotary/Reciprocating) or 15–90 rpm (Rocking/3D)
Amplitude: 30 mm (Rotary/Reciprocating) / 25 mm (Rocking) / 3–15° tilt (3D)
Tray Size: 250 × 230 mm, Max Load: 5 kg (including jig)
Control System: Microcomputer Intelligent PID, LED Digital Display
Power Supply: AC 90–260V, 50–60 Hz, Wide Voltage Range
Functions: Intelligent speed control, low-speed start, memory, overload protection, power-off recovery
