Evaporation Equipment
You are here: home » Products » Evaporation Equipment

Product Category

Evaporation Equipment

Evaporation equipment plays a vital role in modern laboratories by enabling efficient solvent removal, sample concentration, and purification under controlled conditions. Commonly used in chemical, pharmaceutical, biological, and food laboratories, these systems help improve workflow efficiency, maintain sample integrity, and support scalable processing needs.


We offer a comprehensive range of evaporation solutions, including:

  • Rotary Evaporators: Designed for gentle and efficient solvent evaporation, rotary evaporators are ideal for routine distillation tasks in organic chemistry and sample preparation. Our selection includes both manual and automatic models with advanced temperature and vacuum control features.

  • Vacuum Evaporators: These systems accelerate evaporation by lowering the boiling point of solvents under vacuum. Suitable for heat-sensitive samples, vacuum evaporators are widely used in analytical, environmental, and biochemical applications requiring high-throughput and reproducibility.

  • Evaporation Accessories: To ensure optimal performance and versatility, we provide a full range of accessories including glassware sets, vacuum pumps, recirculating chillers, condensers, and sealing components compatible with various evaporation systems.

  • Concentrators: Ideal for parallel sample processing and volume reduction, concentrators use centrifugal force, vacuum, or gas blow-down to concentrate biological, pharmaceutical, or chemical samples. They are commonly used in genomics, proteomics, and drug discovery workflows.

  • Freeze Dryers / Lyophilizers: Designed for long-term sample preservation, freeze dryers use low temperature and vacuum to remove moisture through sublimation. They are widely used for stabilizing biological, pharmaceutical, and chemical samples without compromising structure or activity. Commonly applied in drug development, biotechnology, food research, and clinical diagnostics.

  • Ultrasonic Cleaners: Ultrasonic cleaners use high-frequency sound waves to create microscopic cavitation bubbles that remove contaminants from surfaces and hard-to-reach crevices. Ideal for cleaning laboratory glassware, instruments, and delicate components, these devices are widely used in research labs, medical facilities, electronics, and industrial settings. Heated and digital models offer enhanced cleaning performance and precision.


Whether for routine laboratory evaporation or specialized applications requiring precision control, our evaporation equipment solutions are designed to meet a wide range of research and industrial needs. Explore our product categories to find the right system and components for your lab.


  • Portable Laboratory Cooler PL-1 – Rapid Refrigeration and Temperature Maintenance for Viscosity and Density Testing
    Function: Portable cooler for rapid refrigeration, temperature maintenance, and auxiliary cooling in laboratories
    Compatibility: Suitable for rotation viscometer, foaming characteristics tester, density tester, kinematic viscometer, and other instruments
    Power & Refrigeration: AC 220V ±10%, 50Hz, 200W, completely sealed compressor, R134a refrigerant
    Temperature Control: Accuracy ±0.5℃, ambient 5℃ to 35℃, relative humidity ≤85%
    Dimensions & Portability: 400×450×300 mm, small and portable design
    Operation Environment: Avoid violent vibration, magnetic fields, dust, or corrosive gases

    Model: PL-1
    Add to Basket
  • PE-3000E 3L Rotary Evaporator with Digital Display, Upright Coil Condenser, and Electric Lift
    Rotary evaporator with 3L rotary bottle and 2L collection bottle, suitable for evaporation, concentration, and solvent recovery
    Integrated upright double-layer serpentine coil condenser for high recovery efficiency
    Brushless motor with stepless electronic speed regulation, rotation 0-200 rpm, LCD display for speed and temperature
    Aluminum alloy + PTFE composite heating pot with PT100 sensor, temperature range room temp–99℃ ±1℃, 1200W heating power
    Electric lift with 120mm stroke, easy operation via tilt-type handle switch, dual fuses for rotation and heating safety
    High borosilicate glass and PTFE components in contact with material, vacuum 0.098Mpa, dosing and vacuum suction valves included
    Compact footprint 690490(810-930) mm, total power 1260W, net weight 21.5kg, package 26kg

    Model: PE-3000E
    Add to Basket
  • PE-3002 30L Rotary Evaporator with Digital Display, Vertical Coil Condenser, and Electric Bath Lift
    Rotary evaporator with 30L rotary bottle and 20L collection bottles, ideal for evaporation, distillation, concentration, and solvent recovery
    Vertical three-layer serpentine coil condenser with main and auxiliary cooling for high efficiency and recovery rate
    Brushless motor with frequency converter for rotation, handwheel bath lift 180mm, speed 0-120 rpm, digital display for speed and temperature control
    Heating bath 76L with K-type sensor and stainless steel probe, temperature range room temp–180℃ ±1℃, thermostatic control, over-temperature and anti-dry protection
    PTFE + glass discharge and dosing valves, vacuum switching valve allows continuous collection and discharge, vacuum 0.095Mpa
    Construction with high borosilicate glass, PTFE, stainless steel, and corrosion-resistant aluminum alloy frame for safety and durability
    Overall dimensions 13307302340mm, total power rotary 220V/50Hz, heating 380V/50Hz, package weight 186kg

    Model: PE-3002
    Add to Basket
  • PE-5003 Large-Scale 50L Rotary Evaporator with Electric Lift, Vertical Coil Condenser, and Digital Display
    Rotary evaporator with 50L rotary bottle and 20L collection bottles, designed for large-scale evaporation, distillation, and solvent recovery
    Vertical three-layer serpentine coil condenser with main and auxiliary cooling for efficient condensation and high recovery rate
    Brushless motor with frequency converter for rotation, handwheel bath lift 180mm, speed 0-120 rpm, digital display for speed and temperature control
    Heating bath 76L with K-type sensor and stainless steel probe, temperature range room temp–180℃ ±1℃, thermostatic control, over-temperature and anti-dry protection
    PTFE + glass discharge and dosing valves, vacuum switching valve allows continuous collection and discharge, vacuum 0.095Mpa
    Construction with high borosilicate glass, PTFE, and corrosion-resistant stainless steel and aluminum alloy frame for safety and durability
    Dimensions 13307302340mm, total power 8180W, rotary 220V/50Hz, heating 380V/50Hz, package weight 186kg

    Model: PE-5003
    Add to Basket
  • PR-1050 Large-Scale 50L Rotary Evaporator with Electric Lift, Vertical Coil Condenser, and LCD Display
    Rotary evaporator with 50L rotary bottle and 20L collection bottles, suitable for large-scale evaporation, distillation, and solvent recovery
    Vertical three-layer serpentine coil condenser with main and auxiliary cooling for high recovery efficiency
    Brushless motor for rotation and lifting, electric lift stroke 215mm, speed 0-120 rpm, LCD display for rotation, temperature, and lift control
    Heating bath 76L with PT100 sensor and stainless steel probe, temperature control range room temp–180℃ ±1℃, over-temperature and anti-dry protection
    PTFE + glass discharge and dosing valves, vacuum switching valve for continuous collection, high sealing performance, vacuum 0.095Mpa
    Construction with high borosilicate glass and PTFE, corrosion-resistant stainless steel and aluminum alloy frame, safe and durable
    Dimensions 13907002300mm, total power 8140W, voltage 380V/50Hz, package weight 142kg

    Model: PR-1050
    Add to Basket
  • PE Series Rotary Evaporators 1L/3L/5L Manual Lift with Vertical Condenser and Digital Display
    Rotary evaporator with manual bath lift, lifting stroke 120mm, suitable for 1L, 3L, and 5L flasks
    Vertical condenser options: double-pipe convection for inorganic solvents, single-pipe water/ice-cooled for organic solvents
    High borosilicate glass rotating shaft with PTFE sealing, stainless steel/aluminum alloy structure for corrosion resistance
    Electronic stepless speed regulation 0-120 rpm, digital speed and temperature display, intelligent temperature control 0-400℃ ±1℃
    Stainless steel movable heating bath, strong corrosion resistance, long service life
    Vacuum display included, continuous feeding and PTFE discharge valve (model dependent)
    Dimensions vary by model: PE-201D, PE-301, PE-501; voltage 220V/50Hz; optional explosion-proof inverter and motor

    Model: PE-201D、301、501
    Add to Basket
  • PE100-Pro Digital Rotary Evaporator 5L Motorized Lift with LCD Display and USB Interface
    5L digital rotary evaporator with motorized lift and automatic safety lift in power failure
    Brushless DC motor, rotation speed 20-280 rpm, clockwise and counter-clockwise rotation
    LCD display shows rotation speed, heating temperature, and time; timer adjustable 1-999 min
    Heating bath compatible with water or oil, temperature range: room temp to 180°C, accuracy ±1°C (water), ±3°C (oil)
    Vertical condenser with 1700 cm² surface area for efficient cooling; chemically resistant PTFE sealing ring
    USB interface for data documentation and PC control; wide variety of compatible glassware
    Dimensions 465×457×583mm, weight 15kg, voltage 100-120/200-240V, 50/60Hz, protection class IP20

    Model: PE100-Pro
    Add to Basket
  • -55°C Freeze Dryer for Laboratory Use | 14kg Vacuum Lyophilizer for Aqueous Solutions – PNET16001
    Cold Trap Temperature: ≤ -55°C, reaches -55°C from room temperature within 10 minutes
    Water Capture Capacity: 14 kg, ideal for medium-throughput freeze-drying tasks
    Freeze-Drying Efficiency: 6 kg/24h, suitable for daily laboratory sample processing
    Cold Trap Volume: 23 L, supports large-volume condensation
    Sample Capacity: Compatible with 8–24 sample vials (manifold type)
    Vacuum Performance: Ultimate vacuum ≤ 1.33 Pa, pumping speed ≥ 120 L/min
    Control System: Touchscreen interface with both manual and automatic modes, one-click hot air defrost

    Model: PNET 16001
    Add to Basket
  • -85°C Large Capacity Freeze Dryer | 14kg Vacuum Lyophilizer for Laboratory And Organic Solvent – PNET16002
    Cold Trap Temperature: ≤ -85°C, reaches in 20 minutes
    Water Capture Capacity: 14 kg, Freeze-drying efficiency: 6 kg/24h
    Cold Trap Volume: 23 L, Vacuum Degree ≤1.33 Pa
    Sample Capacity: 8–24 bottles
    Vacuum Pumping Speed: ≥120 L/min, Oil mist filter included
    Dimensions / Weight: 475×700×970 mm / 80 kg

    Model: PNET 16002
    Add to Basket
  • -85°C Laboratory Freeze Dryer | Vacuum Lyophilizer for Aqueous & Organic Solvents – PNET 6002
    Cold Trap Temperature: ≤ -85°C (reaches in 20 minutes)
    Freeze-Drying Area: 0.22 – 0.4 ㎡, 4-layer tray system (φ270mm)
    Water Capture Capacity: 4 kg, Freeze-drying efficiency: 2.2 kg/24h
    Vacuum System: ≤1.33 Pa, pumping speed ≥130 L/min, oil mist filter included
    Compressor Power: 1400W, Cold trap volume ≥10 kg
    Dimensions / Weight: 475×700×1050mm / 73 kg

    Model: PNET 6002
    Add to Basket
