24X-160X, 48X-320X, 12X-80X magnification with 1:6.5 zoom ratio, adjustable monocular viewing tube
Working distance 100mm (extendable to 165mm) with LED ring light, brightness adjustable
High-definition 1/3 inch image sensor, 1920×1080P@60FPS, effective pixels high definition
HDMI, USB, TF card output, supports 2MP image capture and 1080P video recording
Measurement functions: point coordinates, crosshair, straight/curve length, radius and circle distance, geometric area
Optional accessories: X-Y mobile stage, grid plate, additional 0.5X/2X lens, USB flash drive
Arm bracket 330mm with 220mm focusing range, base size 321×261mm, vertical rotation and horizontal mirroring


TMZ180 Series Zoom Microscope, Total Magnification 6.2X–50X or 3.1X–250X with Optional Auxiliary Objectives and Eyepieces
Sliding Binocular or Trinocular Head, 45° Inclined, Interpupillary Distance 52–75mm
Zoom Objective 0.62X–5X, High Eyepoint Wide Field WF10X/23mm Eyepiece, Binocular Diopter ±6
Field of View Φ4.6–Φ37mm, Working Distance 110mm, Focusing Range 60mm
LED Upper and Bottom Illumination, 1W Each, Brightness Adjustable
Optional Accessories: WF15X/WF20X Eyepieces, LED Ring Light, Digital/SLR Camera Adapter, 0.5X–1X C Adapter, Double Boom Universal Stand
Versatile Microscope for Laboratory, Teaching, and Industrial Applications


TL-165-XTWZ Stereo Microscope, Total Magnification 7X–45X (3.5X–180X with Optional Auxiliary Objectives and Eyepieces)
Compensation Binocular or Trinocular Head, 45° Inclined, Interpupillary Distance 55–75mm
Zoom Objective 0.7X–4.5X, High Eyepoint Wide Field WF10X Eyepiece, Binocular Diopter ±6
Field of View Φ5–Φ30mm, Working Distance 30–160mm
Universal Cast Iron Base with Stainless Steel Column, Column Height 368mm, Base Size 210×260mm, Horizontal Size 510mm
Optional Accessories: HD Digital Camera 2–20MP, Windows/Android Tablet, Additional Objectives 0.5X/2X, LED Ring Light Adjustable Brightness
Durable, Flexible Observation for Laboratory, Teaching, and Research Applications


TL-165 Series Stereo Microscope, Total Magnification 7X–45X (3.5X–180X with Optional Auxiliary Objectives and Eyepieces)
Compensation Binocular or Trinocular Head, 45° Inclined, Interpupillary Distance 55–75mm
Zoom Objective 0.7X–4.5X, High Eyepoint Wide Field WF10X Eyepiece, Binocular Diopter ±6
Field of View Φ5–Φ30mm, Working Distance 30–160mm, Focusing Range 50–100mm
LED Upper and Bottom Illumination, Brightness Adjustable, Stand Lifting Range 20–185mm
Optional Accessories: WF15X/WF20X Eyepieces, 9-inch Tablet PC, CCD Adapter, Double Boom Universal Stand
Durable Packaging: Foam + Carton


TL-168 Stereo Microscope, 8X–50X (4X–200X Optional) Continuous Zoom with Wide Field WF10X Eyepiece
Binocular or Trinocular Viewing Head, Interpupillary Distance 52–75mm, Standard Camera Interface for Trinocular
Continuous Zoom Objective 0.8X–5X, Par-focal; Optional Auxiliary Objectives 0.5X, 0.7X, 2X
Vertical Arm Coaxial Coarse & Fine Focusing, Range 60mm; X-Y Double-Layer Mechanical Stage Optional
LED Oblique and Transmitted Bottom Illumination, Brightness Adjustable, Illumination Angle Adjustable
Wide Field Optional Eyepieces WF20X, USB/HDMI Camera Systems, Android Touch Screen Display Optional
Working Distance 45–220mm, Field of View Φ5–Φ30mm


Magnification Range: 6.7x – 45x (zoom ratio 1:6.7)
Objective Lens: 0.67x – 4.5x
Eyepiece: Wide Field WF10X/22mm, adjustable
Working Distance: 105mm
Observation Head: 45° inclined, interpupillary distance 54–75mm
Stand Options: Vertical column or articulated arm, height up to 380mm
Illumination (optional): Upper and lower LED / Halogen + Fluorescent lighting


Zoom Range: 0.7x – 4.5x, Total Magnification: 7x – 45x
Eyepiece: Wide Field WF10X/20mm, Interpupillary Distance: 55–75mm
Observation Head: 45° inclined, binocular
Working Distance: 100mm, long-range clear observation
Stand Options: Column stand / arm stand / universal base
Lighting: Optional halogen, fluorescent, or upper & lower LED with adjustable brightness
Applications: Suitable for PCB, LED, electronics, medical and industrial inspection


Continuous zoom objective: 0.7X to 4.5X, smooth and flicker-free magnification.
Optical magnification range: 0.12X to 18X (with CCD eyepiece and auxiliary objectives).
Working distance options: 198mm, 131mm, 96mm, 63mm, depending on lens configuration.
Interchangeable CCD eyepieces: 0.35X / 0.5X / 0.75X / 1X / 1.5X / 2X.
Optional objective lenses: 0.5X / 0.75X / 1X / 1.5X / 2X.
Wide field of view: up to 46mm, ensuring large area observation.
Compatible with various lighting sources and stand bases.


Eyepieces Available: WF10X/20, WF15X/15, WF20X/10
Objectives: 1x / 2x / 3x / 4x switchable
Total Magnification: 10x to 80x depending on eyepiece and objective combination
Field of View: Ranges from 20mm (WF10X/1x) to 2.5mm (WF20X/4x)
Working Distance: Long 100mm for wide sample compatibility
Viewing Head: Binocular observation head
Applications: Ideal for precision inspection, industrial quality control, and educational use


Viewing head: Trinocular Viewing Head
Zoom body: 0.7x-4.5x continuous magnification
Eyepiece: WF10X/18mm wide angle eyepiece with eyecups
Objective lens: 1x
CCD eyepiece: 0.5x
AM35 camera: AV Output
8’ LCD display: AV input/VGA input with crosshair, multi-language
Lighting: LED ring light (24 LEDs), adjustable light
