TYC-L Series
TOP
Features:
Temperature control:
Display accuracy of 0.1 ℃ ℃;
Microcomputer digital control, real-time display of temperature and humidity;
The temperature inside the box is controlled within the range of 4 ± 1 ℃;
Configure temperature and humidity display, recording, and data transmission functions as required to meet GSP requirements;
The optional electronic printing temperature record only tracks and monitors temperature changes throughout the entire process, making it easy to trace.
Safety system
Multiple fault alarms;
High and low temperature alarm, power outage alarm, door opening alarm, sensor failure alarm;
Multiple alarm methods;
Sound buzzing alarm, flashing light alarm;
Refrigeration system
Using well-known brand compressors, with stable and reliable performance and long service life;
Using branded fans, the performance is stable and long-lasting, with low noise;
Unique fluorine free and environmentally friendly refrigerant:
User-friendly design
Convenient access: shelves with label strips for easy identification and storage of drugs by users;
High security: The door is equipped with a safety lock, ensuring high security;
Energy saving: Built in lighting, high brightness and energy-saving, making the reagents inside the cabinet clear at a glance;
Strong applicability: Designed with a wide voltage range of 187V~242V, suitable for environments with unstable voltage.
Features:
Temperature control:
Display accuracy of 0.1 ℃ ℃;
Microcomputer digital control, real-time display of temperature and humidity;
The temperature inside the box is controlled within the range of 4 ± 1 ℃;
Configure temperature and humidity display, recording, and data transmission functions as required to meet GSP requirements;
The optional electronic printing temperature record only tracks and monitors temperature changes throughout the entire process, making it easy to trace.
Safety system
Multiple fault alarms;
High and low temperature alarm, power outage alarm, door opening alarm, sensor failure alarm;
Multiple alarm methods;
Sound buzzing alarm, flashing light alarm;
Refrigeration system
Using well-known brand compressors, with stable and reliable performance and long service life;
Using branded fans, the performance is stable and long-lasting, with low noise;
Unique fluorine free and environmentally friendly refrigerant:
User-friendly design
Convenient access: shelves with label strips for easy identification and storage of drugs by users;
High security: The door is equipped with a safety lock, ensuring high security;
Energy saving: Built in lighting, high brightness and energy-saving, making the reagents inside the cabinet clear at a glance;
Strong applicability: Designed with a wide voltage range of 187V~242V, suitable for environments with unstable voltage.
Technical data
Model | TYC-L288 | TYC-L388 | TYC-L668 |
Volume (L) | 288 | 388 | 668 |
Temperature range (℃) | 2 ~ 8 | ||
Rated Voltage/Frequency (V/Hz) | 220/50 | ||
Rated power (W) | 300 | 320 | 420 |
Power consumption (KWh/24h) | 3.6 | 4.3 | 5.5 |
Type of electric shock protection | I | ||
Climate types | N | ||
Net weight (kg) | 94 | 107 | 155 |
Noise (dBA) | 52 | 52 | 55 |
Insulation layer thickness (mm) | 40 | 40 | 60 |
Laying the net/board (layer) | 5 | 5 | 5 |
Product size (mm) | 605*675*1610 | 605*675*1925 | 1220*625*1885 |
Inner box dimensions (mm) | 525*575*1050 | 525*575*1366 | 1100*504*1325 |
Packaging material (conventional) | Wooden pallet + carton | ||
Packaging size (regular) | 685*765*1705 | 685*765*2025 | 1300*705*1985 |
Structure | Bottom-mounted unit | Bottom-mounted unit | Bottom-mounted unit |
Certificate |
Product parameters
Model | TYC-L868 | TYC-L1008 |
Volume (L) | 868 | 1008 |
Temperature range (°C) | 2~8 | |
Rated voltage/frequency (V/Hz) | 220/50 | |
Rated power (W) | 480 | 500 |
Power consumption (KWh/24h) | 6.1 | 6.5 |
Protection against electric shock types | I | |
Climate type | N | |
Net weight (kg) | 178 | 194 |
Noise (dBA) | 55 | 555 |
Insulation layer thickness (mm) | 60 | 60 |
Set aside net/board (layer) | 5 | 5 |
Product size (mm) | 1220*755*1885 | 1220*855*1885 |
Inner box dimensions (mm) | 1100*634*1325 | 1100*734*1325 |
Packaging Material (Conventional) | Wooden pallet + carton | |
Packaging size (regular) | 1300*835*1985 | 1300*940*1985 |
Structure | Bottom-mounted unit | Bottom-mounted unit |
Certificate |
Product configuration
Style | Vertical | Cabinet lighting lamp | LED | Roller form | Self-locking universal rubber rollers |
Color | Off-white orange pattern | Thermostat | Microcomputer LED digital display temperature controller | Outer door | Electric heating tempered glass door |
Cooling method | Air-cooled | Insulation materials | Cyclopentane polyurethane foam insulation layer | Inner door | Acrylic panel material |
Compressor | SECOP | Refrigerant | R134a | Hold hands | Embedded pull handle / Aluminum alloy pull handle |
Evaporator | Copper tube finned evaporator | Outer box material | Cold-rolled steel sheet, electrostatic spraying | Door sealing strip | Rubber band airbag door seal |
Condenser | Copper tube finned condenser | Inner box material | 304 stainless steel | Alarm method | Bee buzzing sound and display flickering alarm |
Evaporative fan | Yes | Lock | Alloy industrial cabinet lock | Alarm function | High and low temperature alarm, sensor failure alarm, door open alarm, power outage alarm |
Condenser fan | EBM | Basketball net | Plastic-coated mesh basket | ||
Optional configuration | 304 stainless steel inner container / foamed door / window door / remote monitoring / USB data interface / temperature recorder / printer |
Technical data
Model | TYC-L288 | TYC-L388 | TYC-L668 |
Volume (L) | 288 | 388 | 668 |
Temperature range (℃) | 2 ~ 8 | ||
Rated Voltage/Frequency (V/Hz) | 220/50 | ||
Rated power (W) | 300 | 320 | 420 |
Power consumption (KWh/24h) | 3.6 | 4.3 | 5.5 |
Type of electric shock protection | I | ||
Climate types | N | ||
Net weight (kg) | 94 | 107 | 155 |
Noise (dBA) | 52 | 52 | 55 |
Insulation layer thickness (mm) | 40 | 40 | 60 |
Laying the net/board (layer) | 5 | 5 | 5 |
Product size (mm) | 605*675*1610 | 605*675*1925 | 1220*625*1885 |
Inner box dimensions (mm) | 525*575*1050 | 525*575*1366 | 1100*504*1325 |
Packaging material (conventional) | Wooden pallet + carton | ||
Packaging size (regular) | 685*765*1705 | 685*765*2025 | 1300*705*1985 |
Structure | Bottom-mounted unit | Bottom-mounted unit | Bottom-mounted unit |
Certificate |
Product parameters
Model | TYC-L868 | TYC-L1008 |
Volume (L) | 868 | 1008 |
Temperature range (°C) | 2~8 | |
Rated voltage/frequency (V/Hz) | 220/50 | |
Rated power (W) | 480 | 500 |
Power consumption (KWh/24h) | 6.1 | 6.5 |
Protection against electric shock types | I | |
Climate type | N | |
Net weight (kg) | 178 | 194 |
Noise (dBA) | 55 | 555 |
Insulation layer thickness (mm) | 60 | 60 |
Set aside net/board (layer) | 5 | 5 |
Product size (mm) | 1220*755*1885 | 1220*855*1885 |
Inner box dimensions (mm) | 1100*634*1325 | 1100*734*1325 |
Packaging Material (Conventional) | Wooden pallet + carton | |
Packaging size (regular) | 1300*835*1985 | 1300*940*1985 |
Structure | Bottom-mounted unit | Bottom-mounted unit |
Certificate |
Product configuration
Style | Vertical | Cabinet lighting lamp | LED | Roller form | Self-locking universal rubber rollers |
Color | Off-white orange pattern | Thermostat | Microcomputer LED digital display temperature controller | Outer door | Electric heating tempered glass door |
Cooling method | Air-cooled | Insulation materials | Cyclopentane polyurethane foam insulation layer | Inner door | Acrylic panel material |
Compressor | SECOP | Refrigerant | R134a | Hold hands | Embedded pull handle / Aluminum alloy pull handle |
Evaporator | Copper tube finned evaporator | Outer box material | Cold-rolled steel sheet, electrostatic spraying | Door sealing strip | Rubber band airbag door seal |
Condenser | Copper tube finned condenser | Inner box material | 304 stainless steel | Alarm method | Bee buzzing sound and display flickering alarm |
Evaporative fan | Yes | Lock | Alloy industrial cabinet lock | Alarm function | High and low temperature alarm, sensor failure alarm, door open alarm, power outage alarm |
Condenser fan | EBM | Basketball net | Plastic-coated mesh basket | ||
Optional configuration | 304 stainless steel inner container / foamed door / window door / remote monitoring / USB data interface / temperature recorder / printer |
