TLC Series
TOP
Features:
Foam: sing new cyclopentane with enough quantity as foaming material, locking all the coldness, increasing foaming density in a more environmentally friendly way.
Body: high quality pre coating steel panel, strong anti-corrosion property, non-rusting and non-discolouring.
Cooling tank: stainless steel material, can put the water in it, make beverage in long cooling, save the power and never rusting.
Equipped with adjustable baskets to make full use of the space.
Invisible with easy operation
The safety lock can prevent random opening
High strength castor for easy movement
Novel ventilation hole design, beautiful and strengthen heat dissipation effect, extend the compressor lifetime
Mechanical temperature control with adjustable thermostat: temperature can be adjusted freely between cooling and freezing.
Features:
Foam: sing new cyclopentane with enough quantity as foaming material, locking all the coldness, increasing foaming density in a more environmentally friendly way.
Body: high quality pre coating steel panel, strong anti-corrosion property, non-rusting and non-discolouring.
Cooling tank: stainless steel material, can put the water in it, make beverage in long cooling, save the power and never rusting.
Equipped with adjustable baskets to make full use of the space.
Invisible with easy operation
The safety lock can prevent random opening
High strength castor for easy movement
Novel ventilation hole design, beautiful and strengthen heat dissipation effect, extend the compressor lifetime
Mechanical temperature control with adjustable thermostat: temperature can be adjusted freely between cooling and freezing.
Technical data
Model | TLC-L160 | TLC-L260 | TLC-L360 | TLC-L460 |
Volume (L) | 160 | 260 | 360 | 460 |
Temperature range (℃) | 2~8 | |||
Rated voltage/Frequency (V/Hz) | 220/50 | |||
Rated power (W) | 240 | 280 | 300 | 430 |
Power consumption (KWh/24h) | 2.8 | 3.4 | 3.6 | 5.2 |
Electric shock protection Type | I | |||
Climate type | N | |||
Net weight (kg) | 60 | 69 | 80 | 111 |
Noise (dBA) | 52 | 52 | 52 | 54 |
Insulation layer Thickness (mm) | 45 | 40 | 40 | 60 |
Put on the web/board (layer) | 4 | 5 | 5 | 5 |
Product size (mm) | 522*595*1365 | 595*605*1620 | 595*605*1940 | 680*745*1870 |
Inner box dimensions (mm) | 432*500*843 | 515*510*1085 | 515*510*1405 | 560*610*1380 |
Packaging material 1 | Wooden pallet + carton | |||
Packaging size 1 | 590*670*1470 | 670*680*1730 | 670*680*2050 | 750*790*1930 |
Packaging material 2 | Plywood | |||
Packaging size 2 | 610*695*1515 | 690*705*1770 | 690*705*2090 | 770*810*2020 |
Structure | Bottom-mounted unit | Bottom-mounted unit | Downward mounted unit | Top-mounted unit |
Certificate | ||||
Product configuration
Style | Vertical | Condensing fan | Yes | Roller form | Self-locking universal rubber roller |
Color | Milky white | Cabinet interior lighting | LED | Setting aside the net | Plastic coating |
Cooling method | Air-cooled | Thermostat | Microcomputer LED digital display temperature controller | Door | Plastic profile frame glass door |
Compressor | Yes | Thermal insulation materials | Cyclopentane polyurethane foam insulation layer | Hold hands | Embedded handle |
Evaporator | Blow-up evaporator | Refrigerant | R134a | Door seal strip | Rubber seal with airbag door seal |
Condenser | Silicone tube condenser | Outer box, inner box materials | Cold-rolled steel plates, electrostatic spraying | Alarm method | Bee buzz sound and flashing display alarm. |
Evaporative fan | Yes | Lock | Alloy industrial cabinet lock | Alarm function | High and low temperature alarm, sensor failure alarm, door open alarm, power outage alarm. |
Optional configuration | Remote monitoring / USB data interface / Temperature recorder / Printer | ||||
Product parameters
Model | TLC-L660 | TLC-L960 | TLC-L1360 |
Volume (L) | 660 | 960 | 1360 |
Temperature range (℃) | 2～8 | ||
Rated voltage/ Frequency (V/Hz) | 220/50 | ||
Rated power (W) | 490 | 580 | 650 |
Power consumption (KWh/24h) | 5.9 | 7.2 | 7.8 |
Types of electric shock protection | I | ||
Climate types | N | ||
Net weight (kg) | 129 | 141 | 158 |
Noise (dBA) | 54 | 54 | 54 |
Insulation layer Thickness (mm) | 45 | 60 | 60 |
net/board (layer) | 5 | 5 | 5 |
Product size (mm) | 1200*650*1895 | 1200*745*1870 | 1800*745*1870 |
Internal box dimensions (mm) | 1112*560*1232 | 1080*610*1380 | 1680*610*1380 |
Packing material 1 | Wooden pallet + carton | ||
Packaging size 1 | 1270*720*1950 | 1270*790*1930 | 1880*790*1930 |
Packaging material 2 | Plywood | ||
Packaging size 2 | 1290*740*2045 | 1290*810*2020 | 1890*810*2020 |
Structure | Bottom-mounted unit | Top-mounted unit | Top-mounted unit |
Certificate | |||
Product configuration
Style | Vertical | Condenser fan | Yes | Roller form | Self-locking universal rubber roller |
Color | milky white | Cabinet lighting | LED | Lay the net | Plastic coating |
Refrigeration method | Air cooling | Thermostat | Microcomputer LED digital display temperature controller | Door | Plastic profile frame glass door |
Compressor | Yes | Insulation materials | Cyclopentane polyurethane foam insulation layer | Hold hands | Embedded pull handle |
Evaporator | Blown-up evaporator | Refrigerant | R134a | Door sealing strip | Rubber seal strip for airbag door |
Condenser | Silicone tube condenser | Outer box, inner box materials | Cold-rolled steel sheet, electrostatic spraying | Alarm method | Bee buzzing sound and display flashing alarm |
Evaporative fan | Yes | Lock | Alloy industrial cabinet lock | Alarm function | High and low temperature alarm, sensor failure alarm, door open alarm, power failure alarm |
Optional configuration | Remote monitoring/USB data interface/temperature recorder/printer | ||||
