Laboratory Hydrogen-Air Integrated Gas Generator PNGA Series, 100% Hydrogen Purity, Oil-Free Air, 220V

Gas types: Hydrogen (100% purity) and Oil-Free Air (Grade 3)
Hydrogen flow rate: 0–300 ml/min (PNGA-300), 0–500 ml/min (PNGA-500)
Air flow rate: 0–2 L/min (PNGA-300), 0–5 L/min (PNGA-500)
Working pressure: Hydrogen 0.4 MPa, Air 0.4 MPa
Voltage & frequency: 220V ±10%, 50Hz; Maximum power 230–300W
External dimensions (L×W×H): 520×280×400 mm
Net weight: 32–34 kg

Availability:
Quantity:
facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
sharethis sharing button
  • PNGA-300/500

  • TOP

Technical Parameters

Nitrogen-air integrated machine

Model

PNGA-300

PNGA-500

Purity (relative oxygen content)

Hydrogen

99.999%

99.999%

Air

Oil-free Grade 3

Oil-free Grade 3


Work pressure

Hydrogen

0.4Mpa

0.4Mpa

Air

0.4Mpa

0.4Mpa

Flow rate /min

Hydrogen

0-300ml

0-500ml

Air

0-2 L

0-5 L

Supply Voltage

220V±10% 50Hz

Ambient Temperature

0-40℃ Relative humidity<85%

0-45℃ Relative humidity<85%

Ambient conditions

No large amount of dust and corrosive gas

Maximum power

230W

300W

External Dimensions

520X280X400mm (L×W×H)

Weight

32Kg

34Kg
