PT-DE26 Online Conductivity Sensor – RS485/MODBUS, Temperature Compensated, IP68 Waterproof, 0–200 mS/cm
Measuring Range: 0–20 mS/cm, 0–200 mS/cm | Accuracy: ≤±1% | Response Time: ≤15 s
Measured Variables: Conductivity, Resistivity, TDS, Salinity | Temperature Range: 0–60℃, Accuracy: ≤±0.3℃
Built-in temperature sensor with automatic water temperature compensation
Digital Output: RS-485, MODBUS-RTU; Two-way communication, low power consumption (0.5 W)
Construction: Graphite electrode, ink/epoxy/ABS housing, 316L liquid connection, IP68 waterproof
Installation: Flow-through tank, pipe, or sink mounting; Coaxial design ensures stability and anti-interference
Power Supply: 12–24 VDC; Cable length: 5 m standard, customizable
- Model: PT-DE26
