Portable Ozone Meter for Water | DPD Photometric Method Ozone Tester, Handheld Water Quality Analyzer
You are here: home » Products » Water Quality Testing Equipment » Portable Water Quality Analyzers » Portable Ozone Meter for Water | DPD Photometric Method Ozone Tester, Handheld Water Quality Analyzer

Product Category

loading

Portable Ozone Meter for Water | DPD Photometric Method Ozone Tester, Handheld Water Quality Analyzer

Measuring Range: 0.05–2.50 mg/L (ozone in water)
Accuracy: ≤±0.05 mg/L (<1.0 mg/L); ≤±5% (≥1.0 mg/L)
Principle: DPD photometric method, 520 nm LED light source
Battery Life: >24 hours continuous use
Protection: IP65 waterproof, portable lightweight design
Dimension & Weight: 128×70×48 mm, 188 g (with battery)
Operating Environment: 0–40°C, ≤90% RH (non-condensing)

Availability:
Quantity:
facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
sharethis sharing button
  • PT-D01F

  • TOP

This instrument is designed for the determination of ozone concentration in water using the DPD photometric method, which has been proved to be simple, fast and highly sensitive in a large number of experiments. The instrument is small, lightweight, portable, and suitable for field and on-site use, and has the following distinctive features.


The instrument is widely used in scientific research institutes, tap water, hospital sewage, swimming pool water, domestic sewage, aquaculture water, environmental monitoring, petrochemical, papermaking, pharmaceutical, printing and dyeing, textile, leather, brewing, electronics, municipal government, colleges and universities, etc., and has been highly praised by the majority of users.


Product features

1. Lightweight and portable: small size, light weight, protection grade IP65.

2. Professional light path design: professional light path design, good stability of the optical system.

3. Fast analysis speed: Low sample and reagent usage, fast analysis speed.

4. Automatic shutdown: Power-saving function with automatic shutdown and long standby time.

5. Simple operation: intuitive display, easy to operate.


Application Scope

- Municipal water

- Public health

- Medical water

- Environmental monitoring


Basic parameters

Measuring Range

0.05〜2.50mg/L

Light source

LED light-emitting diode

Wavelength

520nm

Accuracy

<1.0mg/L error: ≤±0.05mg/L; ≥1.0mg/L error: ≤±5 percent

Principle

DPD photometric method, ozone reacts with DPD reagent to give a red colour to the sample solution

Environment

Temperature 0 to 40°C, relative humidity 0 to 90% (non-condensing)

Battery life

More than 24 hours (without switching off)

Dimension

128×70×48mm

Weight

188g (including battery)
