PT-D01F
TOP
This instrument is designed for the determination of ozone concentration in water using the DPD photometric method, which has been proved to be simple, fast and highly sensitive in a large number of experiments. The instrument is small, lightweight, portable, and suitable for field and on-site use, and has the following distinctive features.
The instrument is widely used in scientific research institutes, tap water, hospital sewage, swimming pool water, domestic sewage, aquaculture water, environmental monitoring, petrochemical, papermaking, pharmaceutical, printing and dyeing, textile, leather, brewing, electronics, municipal government, colleges and universities, etc., and has been highly praised by the majority of users.
This instrument is designed for the determination of ozone concentration in water using the DPD photometric method, which has been proved to be simple, fast and highly sensitive in a large number of experiments. The instrument is small, lightweight, portable, and suitable for field and on-site use, and has the following distinctive features.
The instrument is widely used in scientific research institutes, tap water, hospital sewage, swimming pool water, domestic sewage, aquaculture water, environmental monitoring, petrochemical, papermaking, pharmaceutical, printing and dyeing, textile, leather, brewing, electronics, municipal government, colleges and universities, etc., and has been highly praised by the majority of users.
Product features:
1. Lightweight and portable: small size, light weight, protection grade IP65.
2. Professional light path design: professional light path design, good stability of the optical system.
3. Fast analysis speed: Low sample and reagent usage, fast analysis speed.
4. Automatic shutdown: Power-saving function with automatic shutdown and long standby time.
5. Simple operation: intuitive display, easy to operate.
Application Scope:
- Municipal water
- Public health
- Medical water
- Environmental monitoring
Product features:
1. Lightweight and portable: small size, light weight, protection grade IP65.
2. Professional light path design: professional light path design, good stability of the optical system.
3. Fast analysis speed: Low sample and reagent usage, fast analysis speed.
4. Automatic shutdown: Power-saving function with automatic shutdown and long standby time.
5. Simple operation: intuitive display, easy to operate.
Application Scope:
- Municipal water
- Public health
- Medical water
- Environmental monitoring
Basic parameters | |
Measuring Range | 0.05〜2.50mg/L |
Light source | LED light-emitting diode |
Wavelength | 520nm |
Accuracy | <1.0mg/L error: ≤±0.05mg/L; ≥1.0mg/L error: ≤±5 percent |
Principle | DPD photometric method, ozone reacts with DPD reagent to give a red colour to the sample solution |
Environment | Temperature 0 to 40°C, relative humidity 0 to 90% (non-condensing) |
Battery life | More than 24 hours (without switching off) |
Dimension | 128×70×48mm |
Weight | 188g (including battery) |
