THH-256
TOP
Product advantages:
1. Precise control
· PID algorithm realizes accurate control of temperature and humidity to prevent overshoot oftemperature and humidity
2. Safe and reliable
· Comply with DIN 12880 standard, power-off protection, overload protection, temperaturecontrol three-evel protection
3. Convenient operation
· Program controlled operation, repeated step and step operation
· Fixed value operation, fixed time operation, automatic stop
Product features:
· Convenient operation, constant value operation, regular operation and automatic stop
· Auxiliary menu to realize over rise alam, deviation corection and menu locking
· The air inlet grille can be opened directly to facilitate the cleaning of the condenser
· The double evaporators switch automatically, without affecting frost, and have littledisturbance to the temperature in the box.
· Loop self diagnosis, sensor fault alarm, overtemperature and humidity alarm, water fillingfault alamm, dry burning alarm
· Automatic water supply system, built-in water storage tank in the box, automatic waterreplenishment after water shortage
· The independent digital display temperature limiter is safer to use
· LCD 30 segment program control, repeated step and step operation
· Turbine centrifugal forced air supply, more uniform temperature
· Power off protection, parameter memory , incoming call recovery
· Hidden themal humidification system, with unifomm humidity
· Universal casters at the bottom make it easy to move the box
· Automatic frost, avoiding evaporator icing fault Imported Honeywell humidity sensor
· Special function keys realize temperature setting
Product advantages:
1. Precise control
· PID algorithm realizes accurate control of temperature and humidity to prevent overshoot oftemperature and humidity
2. Safe and reliable
· Comply with DIN 12880 standard, power-off protection, overload protection, temperaturecontrol three-evel protection
3. Convenient operation
· Program controlled operation, repeated step and step operation
· Fixed value operation, fixed time operation, automatic stop
Product features:
· Convenient operation, constant value operation, regular operation and automatic stop
· Auxiliary menu to realize over rise alam, deviation corection and menu locking
· The air inlet grille can be opened directly to facilitate the cleaning of the condenser
· The double evaporators switch automatically, without affecting frost, and have littledisturbance to the temperature in the box.
· Loop self diagnosis, sensor fault alarm, overtemperature and humidity alarm, water fillingfault alamm, dry burning alarm
· Automatic water supply system, built-in water storage tank in the box, automatic waterreplenishment after water shortage
· The independent digital display temperature limiter is safer to use
· LCD 30 segment program control, repeated step and step operation
· Turbine centrifugal forced air supply, more uniform temperature
· Power off protection, parameter memory , incoming call recovery
· Hidden themal humidification system, with unifomm humidity
· Universal casters at the bottom make it easy to move the box
· Automatic frost, avoiding evaporator icing fault Imported Honeywell humidity sensor
· Special function keys realize temperature setting
Technical data
Model | THH-256 | Temperature and humidity control mode | 30 segment program control |
Type | Forced convection | Temperature and humidity setting mode | Touch six buttons to dispiay on LCD |
Temperature range | No humidification:0-65ºC humidification:10-65ºC | Timer | 0-99.9h*30(with timed waiting function) |
Temperature resolution | 0.1ºC | Temperature sensor | Pt100 |
Temperature fluctuation | ±0.5ºC | Humidity sensor | Honeywell humidity sensor |
Temperature distribution accuracy | ±0.8ºC(test point 37ºC) | Internal dimension (width*depth*height) | 500*508*1000mm |
Humidity range | 35%-90%RH | External dimension (width*depth*height) | 668*790*1660mm |
Humidity fluctuation | ±3% | Outer package size (width*depth*height) | 804*944*1778mm |
Liner material | SUS304 | Volume | 256L |
Shell material | Cold plate powder | Diaphragm bearing |
|
Thermal insulation material | Rubber sponge | Diaphragm spacing | 35mm |
Heater material | Stainless steel heating pipe | Voltage | AC220V |
Humidificatin power |
| Power frequency | 50/60Hz |
Cryogen | R134A | Maximum power | 1600W |
Defrost | Non inductive switching of double evaporators | Net weight kg | 130kg |
Humidity control mode | Automatic control,hidden heat humidification | Gross weight kg | 180kg |
Test hole | Inner diameter 52mm | Number of diaphragms | 2 |
Water adding method | Automatic | Number of diaphragm frames | 4 |
External power supply | 1 external five hole | Container loading (20'/40'/40'h) | 14/28/28 |
Technical data
Model | THH-256 | Temperature and humidity control mode | 30 segment program control |
Type | Forced convection | Temperature and humidity setting mode | Touch six buttons to dispiay on LCD |
Temperature range | No humidification:0-65ºC humidification:10-65ºC | Timer | 0-99.9h*30(with timed waiting function) |
Temperature resolution | 0.1ºC | Temperature sensor | Pt100 |
Temperature fluctuation | ±0.5ºC | Humidity sensor | Honeywell humidity sensor |
Temperature distribution accuracy | ±0.8ºC(test point 37ºC) | Internal dimension (width*depth*height) | 500*508*1000mm |
Humidity range | 35%-90%RH | External dimension (width*depth*height) | 668*790*1660mm |
Humidity fluctuation | ±3% | Outer package size (width*depth*height) | 804*944*1778mm |
Liner material | SUS304 | Volume | 256L |
Shell material | Cold plate powder | Diaphragm bearing |
|
Thermal insulation material | Rubber sponge | Diaphragm spacing | 35mm |
Heater material | Stainless steel heating pipe | Voltage | AC220V |
Humidificatin power |
| Power frequency | 50/60Hz |
Cryogen | R134A | Maximum power | 1600W |
Defrost | Non inductive switching of double evaporators | Net weight kg | 130kg |
Humidity control mode | Automatic control,hidden heat humidification | Gross weight kg | 180kg |
Test hole | Inner diameter 52mm | Number of diaphragms | 2 |
Water adding method | Automatic | Number of diaphragm frames | 4 |
External power supply | 1 external five hole | Container loading (20'/40'/40'h) | 14/28/28 |
