TW Series
TOP
Feature
Temperature control
Microcomputer digital control, real-time temperature display, adjustment unit is 0.1 ° C
The temperature inside the box can be adjusted, and the temperature difference between the start and stop can be set;
The alarm temperature value can be set as needed,
Safety system
Equipped with a comprehensive alarm system, with buzzer sound and flashing lights alarm.
It can achieve functions such as high and low temperature alarm, sensor fault alarm, etc;
Multiple protection functions (password protection, frequent start protection, and keeping the refrigeration system running in case of sensor failure)
Refrigeration system
Ultra thick foam layer, double sealed door design, effectively protecting the temperature inside the box;
Optimize the self stacking refrigeration system with imported compressors for strong and efficient refrigeration capacity,
Reasonable evaporator design ensures the most effective flow of refrigerant and good temperature uniformity inside the box;
Unique fluorine free environmentally friendly mixed refrigerant
Single compressor system, stable structure, low failure rate, and low energy consumption;
Adopting German EBM silent fan, with stable and long-lasting performance and low noise
Feature
Temperature control
Microcomputer digital control, real-time temperature display, adjustment unit is 0.1 ° C
The temperature inside the box can be adjusted, and the temperature difference between the start and stop can be set;
The alarm temperature value can be set as needed,
Safety system
Equipped with a comprehensive alarm system, with buzzer sound and flashing lights alarm.
It can achieve functions such as high and low temperature alarm, sensor fault alarm, etc;
Multiple protection functions (password protection, frequent start protection, and keeping the refrigeration system running in case of sensor failure)
Refrigeration system
Ultra thick foam layer, double sealed door design, effectively protecting the temperature inside the box;
Optimize the self stacking refrigeration system with imported compressors for strong and efficient refrigeration capacity,
Reasonable evaporator design ensures the most effective flow of refrigerant and good temperature uniformity inside the box;
Unique fluorine free environmentally friendly mixed refrigerant
Single compressor system, stable structure, low failure rate, and low energy consumption;
Adopting German EBM silent fan, with stable and long-lasting performance and low noise
Technical data
Model | TW-25W58 | TW-25W118 | TW-25W258 | TW-25W358 | TW-25W458 |
TW-45W58 | TW-45W118 | TW-45W258 | TW-45W358 | TW-45W458 | |
TW-65W58 | TW-65W118 | TW-65W258 | TW-65W358 | TW-65W458 | |
TW-86W58 | TW-86W118 | TW-86W258 | TW-86W358 | TW-86W458 | |
TW-105W58 | TW-105W118 | TW-105W258 | TW-105W358 | TW-105W458 | |
TW-135W118 | TW-135W118 | ||||
Volume (L) | 58 | 118 | 258 | 358 | 458 |
Temperature range (℃) | -10～-25/-15～-45/-25～-65/-40～-86/ -86~-105/-115～-135 | -10～-25/-15～-45/-25～-65/-40～-86/-86～-105 | |||
Rated voltage/frequency (V/Hz) | 220/50 | ||||
Rated power (W) | 320/350/360/380/600/950 | 380/400/420/450/850/1020 | 420/430/450/500/950 | 500/530/530/550/1050 | 500/520/530/550/1150 |
Power consumption (KWh/24h) | / /5.1/5.9/10.5/15.8 | 5.7/5.9/5.9/7.3/14.2/18.2 | 6.2/7.1/7.1/8.8/15.5 | 6.5/7.9/8.5/9.6/16.6 | 7.9/8.2/8.9/10.2/19.2 |
Electric shock protection types | I | ||||
Climate types | N | ||||
Net weight (kg) | 83 | 126 | 162 | 184 | 207 |
Noise (dBA) | 60 | 60/70 (below-105℃) | 60/70 (below -105℃) | 60/70 (below -105℃) | 60/70 (below -105℃) |
Insulation layer thickness (mm) | 130 | 150 | 150 | 150 | 150 |
Number of rollers | 4 | 6 | 6 | 6 | 8 |
Product size (mm) | 670*765*1025 | 1270 * 795 * 990 | 1510*895*1095 | 1810 * 895 * 1095 | 2110*895*1095 |
Inner box dimensions (mm) | 410*410*385 | 540*400*560 | 780*500*660 | 1080*500*660 | 1380*500*600 |
Packaging material 1 (conventional) | Wooden box | ||||
Packaging size 1 (mm) (standard) | 860*875*1125 | 1460*905*1090 | 1700*1005*1190 | 2000*1005*1190 | 2305*1005*1190 |
Packaging material 2 | Plywood | ||||
Packaging dimensions 2 (mm) (plywood) | 750*845*1175 | 1350 * 875 * 1140 | 1590*975*1240 | 1890*975*1240 | 2190*975*1240 |
Product configuration
Style | Horizontal | Thermostat | Kaide Microcomputer LED Display Thermostat | Roller form | Self-locking heavy-duty universal rubber roller |
Face Color | Cream-colored with orange stripes | Insulation materials | Cyclopentane polyurethane foam insulation layer | Door | Top development bubble door |
Refrigeration method | Direct cooling | Refrigerant | Fluorine-free environmentally friendly multi-functional blend | Door seal | Rubber airbag, double door seal |
Compressor | SECOP | Outer box material | Cold-rolled steel plate, electrostatic spraying | Hinge | Self-locking spring hinge |
Evaporator | High-quality copper pipe wall evaporator | Inner box material | High-quality food-grade 304 stainless steel | Alarm method | Buzzer sound and flashing display alarm |
Cooling fan | EBM | Lock | Alloy industrial cabinet lock | Attachment | Manual, ice scraper, gloves, keys |
Optional configuration | Little elf temperature control/touch screen/remote monitoring/USB data interface/temperature recorder/printer/external box Cold-rolled sheet coating, inner liner304 stainless steel | ||||
Product parameters
Type 号 | TW-25W60 | TW-25W120 | TW-25W220 | TW-25W320 | TW-25W420 |
TW-45W60 | TW-45W120 | TW-45W220 | TW-45W320 | TW-45W420 | |
TW-65W60 | TW-65W120 | TW-65W220 | TW-65W320 | TW-65W420 | |
TW-80W60 | TW-80W120 | TW-80W220 | TW-80W320 | TW-80W420 | |
Volume (L) | 60 | 120 | 220 | 320 | 420 |
Temperature range (℃) | -5-45/-5~-25/-15～-45/-25～-65/-40～-80/-86/-105 | ||||
Rated voltage/frequency (V/Hz) | 50220/50 | ||||
Rated power (W) | 310/310/330/350 | 320/320/325/370 | 380/380/250/420 | 450/450/480/500 | 480/480/500/530 |
Power consumption (KWh/24h) | 3.5/3.5/4.1/4.7 | 3.8/3.8/4.4/5.1 | 4.2/4.2/4.9/5.9 | 5.7/5.7/7.0/7.8 | 7.2/7.2/8.4/9.5 |
Type of electric shock protection | I | ||||
Climate types | N | ||||
Net weight (kg) | 78 | 88 | 106 | 126 | 146 |
Noise (dBA) | 55 | 55 | 60 | 60 | 60 |
Insulation layer thickness (mm) | 100 | 100 | 100 | 100 | 100 |
Number of rollers | 4 | 4 | 4 | 4 | 4 |
Number of net baskets | 1 | 1 | 1 | 2 | 2 |
Product dimensions (mm) | 670*765*905 | 810 * 765 * 885 | 1160*765*885 | 1530*765*885 | 1680*765*980 |
Inner box dimensions (mm) | 470*470*300 | 700*470*385 | 960*470*600 | 1330*470*600 | 1480*470*680 |
Packaging material 1 (conventional) | Wooden pallet + Carton | ||||
Packaging size 1 (mm) (standard) | 800*875*1075 | 1030*875*1115 | 1290*875*1055 | 1660*875*1055 | 1870*880*1065 |
Packaging material 2 | Plywood | ||||
Packaging size 2 (mm) (plywood) | 770*845*1055 | 1000*845*1095 | 1260*845*1035 | 1630*845*1035 | 1780*845*1135 |
Product parameters
Model | TW-25W520 | TW-25W620 | |
TW-40W520 | TW-40W620 | ||
TW-60W520 | TW-60W620 | ||
TW-80W520 | TW-80W620 | ||
Volume (L) | 520 | 620 | |
Temperature range (°C) | -5 ~ -25 / -15~ -45 / -25 ~ -65 / -40 ~ -80/-86/-105 | ||
Rated voltage/frequency (V/Hz) | 50220 volts, 50 hertz | ||
Rated power (W) | 480/500/500/530 | 500/520/520/550 | |
Power consumption (KWh/24h) | /7.3/8.6/9.7 | /7.8/9.3/10.2 | |
Type of electric shock protection | I | ||
Climate type | N | ||
Net weight (kg) | 153 | 174 | |
Noise (dBA) | 60 | 60 | |
Insulation layer thickness (mm) | 100 | 100 | |
Number of rollers | 6 | ||
Number of net baskets | 2 | 2 | |
Product dimensions (mm) | 1850*895*1005 | 2110*895*1005 | |
Inner box dimensions (mm) | 1220*600*695 | 1480*600*695 | |
Packaging material 1 (conventional) | Ordinary wooden box | Ordinary wooden box | |
Packaging size 1(mm) (regular) | 2040*1005*1085 | 2300*1005*1085 | |
Packaging material 2 | PlywoodPlywood | ||
Packaging size 2 (mm) (Plywood) | 1950*975*1155 | 2210*975*1155 | |
Product configuration
Style | Horizontal | Thermal insulation materials | Cyclopentane polyurethane foam insulation layer | Net basket | Plastic dip coating |
Color | Creamy white with orange stripes | Refrigerant | Fluorine-free environmentally friendly multi-component blend | Door | Top Development Bubble Gate |
Cooling method | Direct cooling | Outer box material | Cold-rolled steel plate, electrostatic spraying | Door seal strip | Rubber band airbag, double-door seal |
Compressor | SECOP | Inner box material | High-quality food-grade 304 stainless steel | Hinge | Self-locking spring hinge |
Condenser | High-quality copper tube fin type air-cooled condenser | Locked | Alloy industrial cabinet lock | Alarm function | High and low temperature alarm, sensor failure alarm |
Condenser fan | EBM | Drain outlet | Yes | Attachment | Basket, manual, ice scraper, gloves, keys |
Thermostat | Kaide microcomputer LED display thermostat | Roller form | Self-locking heavy-duty universal rubber rollers | ||
Optional configuration | Little sprite temperature control/touch screen/remote monitoring/USB data interface/temperature recorder/printer/outer boxCold-rolled sheet spraying, inner liner304 stainless steel | ||||
