Vertical Gel Electrophoresis System TP-SCZ4+ for 1–4 Gels, 100×100mm Glass Plates, Quick Gel Casting & Safe Operation
Glass plate size: 100×100 mm; Gel size: 82×88 mm; Thickness: 1.0–1.5 mm
Supports 1–4 gels simultaneously with dual casting options
Sample volume: 11–15 wells per gel, depending on thickness
Buffer volume: ~1000 ml, ensuring stable pH and efficient cooling
Quick assembly: install glass plates in 15 seconds without knobs
Safety cover with auto-switch-off when lid is removed
Background color design for easy sample loading and gel observation
Supports 1–4 gels simultaneously with dual casting options
Sample volume: 11–15 wells per gel, depending on thickness
Buffer volume: ~1000 ml, ensuring stable pH and efficient cooling
Quick assembly: install glass plates in 15 seconds without knobs
Safety cover with auto-switch-off when lid is removed
Background color design for easy sample loading and gel observation
| Quantity: | |
|---|---|
-
TP-SCZ4+
-
TOP
Technical specifications
Glass plate size（W×L）:100×100 mm
Gel Size（W×L）:82×88 mm
Gel thickness: 1.0、1.5（mm）
Gel amount:1～4（pieces）
Sample volume:（1.0mm）11、15wells；（1.5mm）11、15wells
Buffer Volume:～1000（ml）
Dimension（L×W×H）:220×170×120（mm）
Net weight:2.5（kg）
Characteristic feature
With two gel castings, can cast 1-4 plates of gels at the same time. There are two methods of “casting gel in original position” and “multi-casting gel” for option.
The installation of the glass plate in just 15 seconds, and does not need the knob, fast and convenient.
With the gel making device of normal position, don’t should to moving the glass plate from the process of making gel to electrophoresis, convenient for observation the gel preparation from the glass on both sides, ensures fast set up times and leak-free operation.
Safety cover open button design, convenient opening the cover；
With the background color, easy to be observed in the sample adding and electrophoresis process；
Abundant buffer not only guarantees cooling effects, but also keeps the pH Value stable during the whole experiment process.
Auto-switch-off when the lid is removed.
Technical specifications
Glass plate size（W×L）:100×100 mm
Gel Size（W×L）:82×88 mm
Gel thickness: 1.0、1.5（mm）
Gel amount:1～4（pieces）
Sample volume:（1.0mm）11、15wells；（1.5mm）11、15wells
Buffer Volume:～1000（ml）
Dimension（L×W×H）:220×170×120（mm）
Net weight:2.5（kg）
Characteristic feature
With two gel castings, can cast 1-4 plates of gels at the same time. There are two methods of “casting gel in original position” and “multi-casting gel” for option.
The installation of the glass plate in just 15 seconds, and does not need the knob, fast and convenient.
With the gel making device of normal position, don’t should to moving the glass plate from the process of making gel to electrophoresis, convenient for observation the gel preparation from the glass on both sides, ensures fast set up times and leak-free operation.
Safety cover open button design, convenient opening the cover；
With the background color, easy to be observed in the sample adding and electrophoresis process；
Abundant buffer not only guarantees cooling effects, but also keeps the pH Value stable during the whole experiment process.
Auto-switch-off when the lid is removed.
