High Capacity Laboratory Pure & Ultrapure Water Systems with TOC Online Monitoring – 150L to 400L per Hour

Water production capacity: 150L, 250L, 400L per hour options
Water source adaptability: Suitable for urban tap water with TDS ≥ 100 ppm (Pure-J, Pure-S) or < 100 ppm (Pure-Y)
Multi-stage purification process: Pre-treatment + RO + EDI + polishing mixed bed + purification distribution
Produced water quality: Resistivity ≥ 18.25 MΩ·cm, TOC < 1ppb (Pure-J & Pure-S) or < 3ppb (Pure-Y), Microorganisms ≤ 1 cfu/mL
Equipped with real-time TOC online detection (range 0.05ppb - 2000ppb) and remote monitoring via APP
Advanced safety and automation features: automatic flushing, water level interlock, pressure alarms, leakage protection
Application scope: Biochemical, pharmaceutical, environmental monitoring, HPLC, PCR, molecular biology, and more

Quantity:
Availability:





Inquire Add to Basket

Model:
Pure series
Brand:
TOP

Feature

Fully automatic operation: liquid level interlock fully automatic control, equipped with raw water shortage shutdown protection, system low and high pressure shutdown alarm, water tank high water level automatic stop, medium water level start, system automatic flushing and other fully automatic functions. Simultaneously equipped with manual operation function to meet emergency needs.

Reasonable design: Equipped with efficient pre-treatment and filtration modules, while reducing equipment footprint, it still ensures adaptability to various urban tap water quality. Full display design of instruments and meters,

It can effectively monitor various indicators of the system, with functions such as pure water conductivity, ultra pure water resistivity, TOC online detection, etc. Quantitative water intake: One click quick quantitative water intake function.

Remote monitoring: The application of PLC control combined with the Internet of Things enables remote real-time online monitoring of parameters such as water quality, flow rate, and pressure through an APP.

Human computer page: Touch screen display, convenient and efficient human-machine dialogue page. Password protection: The host has a password key graded protection function.

Safety protection: It has various safety self-locking devices such as perfect leakage protection, pressure protection, power protection, etc.

TOC online detection: equipped with T0C real-time online detection module, detection range: 0.05ppb (μ g/L) -2000ppb (μ g/L)

Optimal configuration: adopting modular and integrated advanced technology design, with stable and superior performance, safe and convenient use, and simple equipment installation and maintenance.

Model	Pure-J-150L	Pure-J-250L	Pure-J-400L
Power	AC380V-50HZ 1-3KW
Inlet water source	Urban tap water (total dissolved solids TDS ≥ 100PPm), suitable for raw water with relatively poor quality, conductivity ≥ 200 μ s/cm, and water temperature of 5-45 ℃
Water production process	Pre treatment+dual stage reverse osmosis+EDI+polishing mixed bed+purification distribution
Water production capacity	150L	250L	400L
Produced water quality	Resistivity ≥ 18.25M Ω• cm (online monitoring), TOC<1ppb， Microorganisms ≤ 1cfu/mL, metal ions ≤ 0.02ppb, Si≤0.1ppb， Heavy metal ions ≤ 0.001ppb, pyrogen ≤ 0.001Eu/mL
Host size	8706601810mm	87013201810	87019801810
Optimal configuration	Paired with TOC online detection module (detection range: 0.05ppb (μ g/L) -2000ppb (μ g/L))
Other configurations	Raw water tank (above 250L), intermediate water tank (optional), terminal water quality tablet real-time display (optional), pure water tank, etc
Scope of application	Production water for biochemical reagents, culture media preparation of food, pharmaceutical preparations, biological preparations, etc., washing of student experiments/vessels, water for humidifiers, cleaning machines, high-pressure sterilization pots and other instruments; Atomic Absorption Spectroscopy (AAS), Atomic Emission Spectroscopy (AES); Ion chromatography (IC); Plasma emission spectroscopy (ICP); High performance gas/liquid chromatography analysis (HPLC); PCR application and analysis, amino acid analysis, protein purification, electrophoresis gel analysis, molecular biology; Applicable to TOC VOC 、HPLC、IVF、PCR、ICP-MS、 Animal and plant cell culture, gene research, in vitro fertilization, electrochemical interface research, molecular biology, toxicology research, pathology research, and more.
Application area	Universities, research institutions, disease control, food and drug testing, environmental monitoring, biomedicine, biochemical analysis experiments, molecular biology life sciences, various high-performance liquid chromatography, ion chromatography, various medical biochemical instruments, analyzer water, environmental experimental analysis water, precision electroplating water, industrial and mining enterprise experimental water and other industry fields.

Model	Pure-S-150L	Pure-S-250L	Pure-S-400L
Power	AC380V-50HZ 1-3KW
Inlet water source	Urban tap water (total dissolved solids TDS ≥ 100PPm), suitable for raw water with relatively poor quality, conductivity ≥ 200 μ s/cm, and water temperature of 5-45 ℃
Water production process	Pre treatment+dual stage reverse osmosis+EDI+polishing mixed bed+purification distribution
Water production capacity	150L	250L	400L
Produced water quality	Resistivity ≥ 18.25M Ω• cm (online monitoring), TOC<1ppb， Microorganisms ≤ 1cfu/mL, metal ions ≤ 0.02ppb, Si≤0.1ppb， Heavy metal ions ≤ 0.001ppb, pyrogen ≤ 0.001Eu/mL
Host size	8706601810mm	87013201810	87019801810
Optimal configuration	Paired with TOC online detection module (detection range: 0.05ppb (μ g/L) -2000ppb (μ g/L))
Other configurations	Raw water tank (above 250L), intermediate water tank (optional), terminal water quality tablet real-time display (optional), pure water tank, etc
Scope of application	Production water for biochemical reagents, culture media preparation of food, pharmaceutical preparations, biological preparations, etc., washing of student experiments/vessels, water for humidifiers, cleaning machines, high-pressure sterilization pots and other instruments; Atomic Absorption Spectroscopy (AAS), Atomic Emission Spectroscopy (AES); Ion chromatography (IC); Plasma emission spectroscopy (ICP); High performance gas/liquid chromatography analysis (HPLC); PCR application and analysis, amino acid analysis, protein purification, electrophoresis gel analysis, molecular biology; Applicable to TOC VOC 、HPLC、IVF、PCR、ICP-MS、 Animal and plant cell culture, gene research, in vitro fertilization, electrochemical interface research, molecular biology, toxicology research, pathology research, and more.
Application area	Universities, research institutions, disease control, food and drug testing, environmental monitoring, biomedicine, biochemical analysis experiments, molecular biology life sciences, various high-performance liquid chromatography, ion chromatography, various medical biochemical instruments, analyzer water, environmental experimental analysis water, precision electroplating water, industrial and mining enterprise experimental water and other industry fields.

Model	Pure-Y-150L	Pure-Y-250L	Pure-Y-400L
Power	AC380V-50HZ 1-3KW
Inlet water source	Urban tap water (total dissolved solids TDS<100PPm), suitable for relatively good raw water quality, conductivity<200 μ s/cm, water temperature 5-45 ℃
Water production process	Pre treatment+single-stage reverse osmosis+EDI+polishing mixed bed+purification distribution
Water production capacity	150L	250L	400L
Produced water quality	Resistivity ≥ 18.25M Ω• cm (online monitoring), TOC<3ppb， Microorganisms ≤ 1cfu/mL, metal ions<0.02ppb, heavy metal ions<0.01ppb
Host size	8706601810mm	87013201810mm	87019801810mm
Optimal configuration	Paired with TOC online detection module (detection range: 0.05ppb (μ g/L) -2000ppb (μ g/L))
Other configurations	Raw water tank (above 250L), intermediate water tank (optional), terminal water quality tablet real-time display (optional), pure water tank, etc
Scope of application	Production water for biochemical reagents, culture media preparation of food, pharmaceutical preparations, biological preparations, etc., water for student experiments/vessel washing, cleaning machines, high-pressure sterilization pots and other instruments; Atomic Absorption Spectroscopy (AAS), Atomic Emission Spectroscopy (AES); Ion chromatography (IC); Plasma emission spectroscopy (ICP); High performance gas/liquid chromatography analysis (HPLC); PCR application and analysis, amino acid analysis, protein purification, electrophoresis gel analysis, molecular biology; Applicable to TOC VOC、HPLC、 IVF、PCR、ICP-MS、 Animal and plant cell culture, gene research, in vitro fertilization, electrochemical interface research, molecular biology, toxicology research, pathology research, and more.
Application area	Universities, research institutions, disease control, food and drug testing, environmental monitoring, biomedicine, biochemical analysis experiments, molecular biology life sciences, various high-performance liquid chromatography, ion chromatography, various medical biochemical instruments, analyzer water, environmental experimental analysis water, precision electroplating water, industrial and mining enterprise experimental water and other industry fields.
