P01 Series Brushless DC Motor Hotplate Stirrer, 5–10L Capacity, 0–2000 rpm, Adjustable Heating 360W–800W

You are here: home » Products » Hotplates & Stirrers » Hotplate Stirrers (Combination) » P01 Series Brushless DC Motor Hotplate Stirrer, 5–10L Capacity, 0–2000 rpm, Adjustable Heating 360W–800W

Product Category

P01 Series Brushless DC Motor Hotplate Stirrer, 5–10L Capacity, 0–2000 rpm, Adjustable Heating 360W–800W

Motor Type: Brushless DC motor with variable speed and stepless speed regulation
Max Stirring Capacity: 5L (P01-1B, P01-1C), 10L (P01-3)
Speed Range: 0–2000 rpm for all models
Heating Power: Adjustable 360W (P01-1B, P01-1C), 800W (P01-3)
Working Plate: Stainless steel, φ145 mm (P01-1B, P01-1C), φ175 mm (P01-3)
Temperature Range: Room temperature to 150°C (within 1L)
Digital Display: Speed and temperature (P01-1B), Temperature only (P01-1C), None (P01-3)

Quantity:
Availability:





Inquire Add to Basket

Model:
P01-1B /P01-1C /P01-3
Brand:
TOP

Brushless DC motor drive, variable speed. Stainless steel heating plate Driven by brushless DC motor; stepless speed regulating

Digital magnetic stirrer heater Laboratory Thermostatic Stirrer Stirring hot plate with thermostat Heating magnetic mixer lab Programmable magnetic stirrer

Related Products

P-H-S10 10-Position Magnetic Hotplate Stirrer – Multi-Sample Heating and Stirring with Adjustable Speed for Laboratory Use

Digital Magnetic Stirrer With Ceramic Plate TH Series

TH-4C/TH-II-4C Digital Magnetic Hotplate Stirrer – Adjustable Heating and Stirring with LCD Display for Laboratory and Industrial Use

Digital Magnetic Hotplate Stirrer TH Series

TH Series Magnetic Hotplate Stirrer – Adjustable Heating and Stirring for Laboratory and Industrial Use

LCD Digital Hotplate Magnetic Stirrer P-H-PRO+

P-H-PRO+ Digital Magnetic Hotplate Stirrer with LCD Display, PT1000 Sensor, and RS232 Data Interface for Laboratory Use

LCD Digital Hotplate Magnetic Stirrer with Timer P-H-ProT

P-H-ProT Magnetic Hotplate Stirrer with LCD Display, Timer, PT1000 Sensor, and RS232 Data Interface

Type	P01-1B	P01-1C	P01-3
Control	Knob	Knob	Knob
(AC) Voltage	220V	220V	220V
Max.stirring capacity	5L	5L	10L
Motor type	Brushless DC Motor	Brushless DC Motor	Brushless DC Motor
Motor Power	10W	10W	15W
(r/min) Speed Range	0~2000	0~2000	0~2000
Working platematerial	Stainless steel	Stainless steel	Stainless steel
(mm) Working plate size	φ145	φ145	φ175
Digital Display	Speed,temperature	Temperature	一
(W) Heating power	360Wadjustable within	360Wadjustable within	800Wadjustable within
℃ Liquidtemperature range	Roomtemperature-150 （Within 1L）	Room temperature-150 （Within 1L）	Room temperature-150 （Within 1L）
Liquid temperature	Sensor	Sensor	Conductive thermometers(Customer provided
(mm) Dimension	225×155×125	225×155×125	290×180×135
(kg) Weight	4.2	4.2	5.9

Type	P01-1B	P01-1C	P01-3
Control	Knob	Knob	Knob
(AC) Voltage	220V	220V	220V
Max.stirring capacity	5L	5L	10L
Motor type	Brushless DC Motor	Brushless DC Motor	Brushless DC Motor
Motor Power	10W	10W	15W
(r/min) Speed Range	0~2000	0~2000	0~2000
Working platematerial	Stainless steel	Stainless steel	Stainless steel
(mm) Working plate size	φ145	φ145	φ175
Digital Display	Speed,temperature	Temperature	一
(W) Heating power	360Wadjustable within	360Wadjustable within	800Wadjustable within
℃ Liquidtemperature range	Roomtemperature-150 （Within 1L）	Room temperature-150 （Within 1L）	Room temperature-150 （Within 1L）
Liquid temperature	Sensor	Sensor	Conductive thermometers(Customer provided
(mm) Dimension	225×155×125	225×155×125	290×180×135
(kg) Weight	4.2	4.2	5.9
