Multi-Position Magnetic Hotplate Stirrer, Brushless DC Motor, 2–10 Stations, 0–1500 rpm, Room Temp to 150°C
Motor Type: Brushless DC motor, variable speed for stable performance
Mixing Stations & Capacity: 2×3L, 4×3L, 6×3L, 4×3L, or 10×1L (model-specific)
Speed Range: 0–1400 rpm or 0–1500 rpm, adjustable per station
Heating Power: 2×600W, 4×600W, 6×360W adjustable, 4×360W adjustable, 10×200W adjustable
Temperature Range: Room temperature to 150°C (within 1L)
Control & Display: Button or knob control, dual LED windows for speed, temperature, and time (model-specific)
Work Plate Material: Aluminum alloy or stainless steel, φ145 mm or φ110 mm
Mixing Stations & Capacity: 2×3L, 4×3L, 6×3L, 4×3L, or 10×1L (model-specific)
Speed Range: 0–1400 rpm or 0–1500 rpm, adjustable per station
Heating Power: 2×600W, 4×600W, 6×360W adjustable, 4×360W adjustable, 10×200W adjustable
Temperature Range: Room temperature to 150°C (within 1L)
Control & Display: Button or knob control, dual LED windows for speed, temperature, and time (model-specific)
Work Plate Material: Aluminum alloy or stainless steel, φ145 mm or φ110 mm
| Availability: | |
|---|---|
| Quantity: | |
-
522G / 524G / P01-1D / P05-1 / P04-1
-
TOP
Brushless Dcmotor drive, variable speed. 2 LED display windows, Every station can be operated independently Stainless steel countertops.
Brushless Dcmotor drive, variable speed. 2 LED display windows, Every station can be operated independently Stainless steel countertops.
Type | 522G | 524G | P01-1D | P05-1 | P04-1 |
Control | Button | Button | Knob | Knob | Knob |
( AC ) Voltage | 220V | 220V | 220V | 220V | 220V |
Mixing site | 2 | 4 | 6 | 4 | 10 |
Max.stirring capacity | 3L×2 | 3L×4 | 3L×6 | 3L×4 | 1L×10 |
Motortype | Brushless DC Motor | Brushless DC Motor | Brushless DC Motor | Brushless DC Motor | Brushless DC Motor |
Motor Power | 8W | 8W | 8W | 8W | 8W |
Digital Display | Speed temperature time | Speed temperature time | Speed temperature time | 一 | 一 |
(r/min) Speed Range | 0~1400 | 0~1400 | 0~1500 | 0~1500 | 0~1500 |
Working plate material | Aluminum Alloy | Aluminum Alloy | Stainlesssteel | Stainless steel | Stainless steel |
(mm) Working plate size | φ145 | φ145 | φ145 | φ145 | φ110 |
(W) Heating power | 2×600W | 4×600W | 6×360W adjustable | 4×360W adjustable | 10×200W adjustable |
℃ Liquid temperature range | Roomtemperature-150（Within 1L） | Room temperature-150（Within 1L） | Roomtemperature-150（Within 1L） | Roomtemperature-150（Within 1L） | Roomtemperature-150（Within 1L） |
Liquid temperature | Sensor | Sensor | Sensor | Conductive thermometers (Customer provided) | (Customer provided)Conductive thermometers |
(mm) Dimension | 380×265×105 | 380×380×145 | 1005×230×130 | 670×230×130 | 645×300×115 |
( kg ) Weight | 9 | 12.8 | 28 | 14.5 | 22 |
Type | 522G | 524G | P01-1D | P05-1 | P04-1 |
Control | Button | Button | Knob | Knob | Knob |
( AC ) Voltage | 220V | 220V | 220V | 220V | 220V |
Mixing site | 2 | 4 | 6 | 4 | 10 |
Max.stirring capacity | 3L×2 | 3L×4 | 3L×6 | 3L×4 | 1L×10 |
Motortype | Brushless DC Motor | Brushless DC Motor | Brushless DC Motor | Brushless DC Motor | Brushless DC Motor |
Motor Power | 8W | 8W | 8W | 8W | 8W |
Digital Display | Speed temperature time | Speed temperature time | Speed temperature time | 一 | 一 |
(r/min) Speed Range | 0~1400 | 0~1400 | 0~1500 | 0~1500 | 0~1500 |
Working plate material | Aluminum Alloy | Aluminum Alloy | Stainlesssteel | Stainless steel | Stainless steel |
(mm) Working plate size | φ145 | φ145 | φ145 | φ145 | φ110 |
(W) Heating power | 2×600W | 4×600W | 6×360W adjustable | 4×360W adjustable | 10×200W adjustable |
℃ Liquid temperature range | Roomtemperature-150（Within 1L） | Room temperature-150（Within 1L） | Roomtemperature-150（Within 1L） | Roomtemperature-150（Within 1L） | Roomtemperature-150（Within 1L） |
Liquid temperature | Sensor | Sensor | Sensor | Conductive thermometers (Customer provided) | (Customer provided)Conductive thermometers |
(mm) Dimension | 380×265×105 | 380×380×145 | 1005×230×130 | 670×230×130 | 645×300×115 |
( kg ) Weight | 9 | 12.8 | 28 | 14.5 | 22 |
