PM-P03H/PM-P04H/PM-P06H/PM-P10H/PM-P15H/PM-P22H/PM-P30H
TOP
1. The inner liner is made of stainless steel SUS304 once stamping molding, no welding place, good waterproof performance.
2. The cleaning basket is made of stainless steel SUS304 mesh screen argon-welded molding to improve the cleaning effect.
3. The ultrasonic transducer transmitter power of the cleaning machine is 50/60W.
4. The ultrasonic working time (1-999 minutes/normal open) is adjustable, suitable for different occasions.
5. 6L and above equipped with exclusive customized drainage device, humanized design, quick discharge of waste water after cleaning.
6. The cleaning temperature is adjustable within the range of room temperature-80℃.
7. The shell of the washing machine is made of imported atomized stainless steel plate, beautiful and generous, acid and alkali resistant.
8. Adopting high quality imported core components, high ultrasonic power conversion efficiency, strong power, good cleaning effect.
9. Unique heat dissipation system, components work more stable.
10. PTC heating, good heating effect, PCB board moisture-proof, anti-corrosion treatment
11. Exclusive use of time, temperature, power three dial code, each function dial code adjustment control control, three program settings (patented technology)
12. Exclusive panel using plexiglass, beautiful and generous, five colors to choose from
13. Exclusive stepless power regulation function, applicable to different ultrasonic treatment areas, closer to the experimental requirements.
1. The inner liner is made of stainless steel SUS304 once stamping molding, no welding place, good waterproof performance.
2. The cleaning basket is made of stainless steel SUS304 mesh screen argon-welded molding to improve the cleaning effect.
3. The ultrasonic transducer transmitter power of the cleaning machine is 50/60W.
4. The ultrasonic working time (1-999 minutes/normal open) is adjustable, suitable for different occasions.
5. 6L and above equipped with exclusive customized drainage device, humanized design, quick discharge of waste water after cleaning.
6. The cleaning temperature is adjustable within the range of room temperature-80℃.
7. The shell of the washing machine is made of imported atomized stainless steel plate, beautiful and generous, acid and alkali resistant.
8. Adopting high quality imported core components, high ultrasonic power conversion efficiency, strong power, good cleaning effect.
9. Unique heat dissipation system, components work more stable.
10. PTC heating, good heating effect, PCB board moisture-proof, anti-corrosion treatment
11. Exclusive use of time, temperature, power three dial code, each function dial code adjustment control control, three program settings (patented technology)
12. Exclusive panel using plexiglass, beautiful and generous, five colors to choose from
13. Exclusive stepless power regulation function, applicable to different ultrasonic treatment areas, closer to the experimental requirements.
Technical parameters:
Model | PM-P03H | PM-P04H | PM-P06H | PM-P10H | PM-P15H | PM-P22H | PM-P30H |
External dimensions | 265x165x230(mm) | 325x175x230(mm) | 380x175x315(mm) | 380x270x315(mm) | 390x325x325(mm) | 580x335x375(mm) | 580x335x375(mm) |
Cleaning tank size | 240x140x100(mm) | 300x155x100(mm) | 300x155x150(mm) | 300x240x150(mm) | 330x300x150(mm) | 500x300x150(mm) | 500x300x200(mm) |
Cleaning tank capacity | 3 L | 4 L | 6 L | 10 L | 15 L | 22.5 L | 30 L |
Ultrasonic power | 100W | 120 W | 180 W | 200 W | 400 W | 500 W | 800 W |
Ultrasonic frequency | 40 KHz | 40 KHz | 40 KHz | 40 KHz | 40 KHz | 53 KHz | 40 KHz |
Heating power | 100W | 100W | 300W | 300W | 400W | 500W | 500W |
Power supply | 220V/50Hz | 220V/50Hz | 220V/50Hz | 220V/50Hz | 220V/50Hz | 220V/50Hz | 220V/50Hz |
Technical parameters:
Model | PM-P03H | PM-P04H | PM-P06H | PM-P10H | PM-P15H | PM-P22H | PM-P30H |
External dimensions | 265x165x230(mm) | 325x175x230(mm) | 380x175x315(mm) | 380x270x315(mm) | 390x325x325(mm) | 580x335x375(mm) | 580x335x375(mm) |
Cleaning tank size | 240x140x100(mm) | 300x155x100(mm) | 300x155x150(mm) | 300x240x150(mm) | 330x300x150(mm) | 500x300x150(mm) | 500x300x200(mm) |
Cleaning tank capacity | 3 L | 4 L | 6 L | 10 L | 15 L | 22.5 L | 30 L |
Ultrasonic power | 100W | 120 W | 180 W | 200 W | 400 W | 500 W | 800 W |
Ultrasonic frequency | 40 KHz | 40 KHz | 40 KHz | 40 KHz | 40 KHz | 53 KHz | 40 KHz |
Heating power | 100W | 100W | 300W | 300W | 400W | 500W | 500W |
Power supply | 220V/50Hz | 220V/50Hz | 220V/50Hz | 220V/50Hz | 220V/50Hz | 220V/50Hz | 220V/50Hz |
