Laboratory Ultrasonic Cleaner with Adjustable Power, Temperature, and Timer | SUS304 Stainless Steel Tank | 3L to 30L Capacity
You are here: home » Products » Evaporation Equipment » Ultrasonic Cleaners » Laboratory Ultrasonic Cleaner with Adjustable Power, Temperature, and Timer | SUS304 Stainless Steel Tank | 3L to 30L Capacity

Product Category

Laboratory Ultrasonic Cleaner with Adjustable Power, Temperature, and Timer | SUS304 Stainless Steel Tank | 3L to 30L Capacity

Cleaning tank capacity: 3L/4L/6L/10L/15L/22.5L/30L (Depend on models)
Cleaning tank size : 240x140x100(mm) /300x155x100(mm) /300x155x150(mm) /300x240x150(mm) /330x300x150(mm) /500x300x150(mm) /500x300x200(mm) (Depend on models)

Availability:
Quantity:
facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
sharethis sharing button
  • PM-P03H/PM-P04H/PM-P06H/PM-P10H/PM-P15H/PM-P22H/PM-P30H

  • TOP

1. The inner liner is made of stainless steel SUS304 once stamping molding, no welding place, good waterproof performance.

2. The cleaning basket is made of stainless steel SUS304 mesh screen argon-welded molding to improve the cleaning effect.

3. The ultrasonic transducer transmitter power of the cleaning machine is 50/60W.

4. The ultrasonic working time (1-999 minutes/normal open) is adjustable, suitable for different occasions.

5. 6L and above equipped with exclusive customized drainage device, humanized design, quick discharge of waste water after cleaning.

6. The cleaning temperature is adjustable within the range of room temperature-80℃.

7. The shell of the washing machine is made of imported atomized stainless steel plate, beautiful and generous, acid and alkali resistant.

8. Adopting high quality imported core components, high ultrasonic power conversion efficiency, strong power, good cleaning effect.

9. Unique heat dissipation system, components work more stable.

10. PTC heating, good heating effect, PCB board moisture-proof, anti-corrosion treatment

11. Exclusive use of time, temperature, power three dial code, each function dial code adjustment control control, three program settings (patented technology)

12. Exclusive panel using plexiglass, beautiful and generous, five colors to choose from

13. Exclusive stepless power regulation function, applicable to different ultrasonic treatment areas, closer to the experimental requirements.


Technical parameters:

ModelPM-P03HPM-P04HPM-P06HPM-P10HPM-P15HPM-P22HPM-P30H
External dimensions265x165x230(mm)325x175x230(mm)380x175x315(mm)380x270x315(mm)390x325x325(mm)580x335x375(mm)580x335x375(mm)
Cleaning tank size240x140x100(mm)300x155x100(mm)300x155x150(mm)300x240x150(mm)330x300x150(mm)500x300x150(mm)500x300x200(mm)
Cleaning tank capacity3 L4 L6 L10 L15 L22.5 L30 L
Ultrasonic power100W120 W180 W200 W400 W500 W800 W
Ultrasonic frequency40 KHz40 KHz40 KHz40 KHz40 KHz53 KHz40 KHz
Heating power100W100W300W300W400W500W500W
Power supply220V/50Hz220V/50Hz220V/50Hz220V/50Hz220V/50Hz220V/50Hz220V/50Hz
