High-Precision PCR Thermal Cycler | 96-Well Gradient & Standard Models for Gene Amplification
You are here: home » Products » PCR Instruments » Gradient PCR Instruments » High-Precision PCR Thermal Cycler | 96-Well Gradient & Standard Models for Gene Amplification

Product Category

High-Precision PCR Thermal Cycler | 96-Well Gradient & Standard Models for Gene Amplification

Sample capacity: 96×0.1/0.2 mL PCR tubes or 96-well microplate
Temperature control range: Block 4~105°C, Heated lid 30~110°C
Temperature accuracy: Display ±0.1°C, Control ±0.3°C, Uniformity ±0.3°C
Maximum temperature ramp rate: 5°C/s
Gradient function (model TP96GC): 30~105°C with gradient span 142°C
Display: 7-inch color touchscreen with storage for 676 user-defined programs
Power failure protection: Yes, with automatic fault detection and alarm

Availability:
Quantity:
facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
sharethis sharing button
  • TP96S / TP96GC

  • TOP

Main Features:

The PCR thermal cycler is general instrument in molecular laboratories and is mainly used for gene amplification in scientific research and clinical area, qualitative PCR gene amplification, gene chip or other gene analysis applications. The gradient thermal cycler has gradient function, which can quickly increase and decrease the temperature. It can achieve temperature uniformity in a single process and can quickly and stably complete polymerase chain reaction (PCR) experiments.



Advantages:

1. Small size, portable and convenient;

2. Hot lid adopts elastic structure design, adaptable to 96-well microplate or 0.1/0.2ml PCR tube;

3. Using imported semiconductor refrigeration chips, the module temperature uniformity is excellent to avoid uneven heat transfer in the module;

4. The fastest heating and cooling rate is 5°C/s, saving valuable experimental time;

5. Humanized standard program file template, which can quickly edit experimental files;

6. Automatic fault detection and alarm function.


Machine parameters:


Model

TP96S

TP96GC

Temp mode

Standard

Gradient

Sample capacity

96×0.1/0.2mL PCR tube/96-wells microplate

Block temp control range

4~105°C

Hot lid temp control range

30~110°C

Temp display accuracy

±0.1°C

Temp control accuracy

±0.3°C

Temp uniformity

±0.3°C

Max temp change rate

5°C/s

Gradient setting range

/

30~105°C

Gradient span

/

1~42°C

Heating module material

Aviation aluminum

Display

7-inch color touch screen

User defined file storage

676 files

Power outage protection

Yes

Dimension

L270×W240×H150mm

Weight

4.8kg

Voltage/Frequency

100~240V;50/60Hz
