High-Capacity Magnetic Stirrer with Weighing Function, Brushless DC Motor, 20L–100L, Digital Display, Optional Heating

Motor Type: Brushless DC motor, customizable speed range & mixing volume
Max Stirring Capacity: 20 L, 50 L, or 100 L (model-specific)
Weighing Range: 50 kg, 100 kg, or 250 kg with high-precision brand sensor
Speed Range: 0–1400 rpm, adjustable, digital speed display
Heating Power (PYP20): With temperature control (100L model, aluminum alloy plate)
Digital Display: Weight, speed, time, and temperature (PYP20)
Work Plate Material: Stainless steel (PYP16), aluminum alloy (PYP20)

Availability:
Quantity:
facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
sharethis sharing button
  • PYP16-20(20L) / PYP16(50L) / PYP16(100L) / PYP20(100L)

  • TOP

PYP20 weighing constant temperature magnetic stirer integrates electronic scale and large capacity, high-power heating magnetic stirer. Electronic scale adopts high-quality brand sensor, digital partadopts high-precisionA/Dconversion, high resolution, brushless DCmotordrive, aluminum alloy worktable, and each function has digital display. The company's own motor, special speed range and mixing volume can be customized.


Type

PYP16-20(20L)

PYP16(50L)

PYP16(100L)PYP20(100L)

Control

Button

Button

Button

Button

(AC) Voltage

220V

220V

220V

220V

Max.stirring capacity

20L

50L

100L

100L

Weighing range

50kg

100kg

250kg

250kg

Motor type

BrushlessDC Motor

Brushless DC Motor

Brushless DC Motor

Brushless DC Motor

Motor Power

40W

100W

150W

150W

Digital Display

Weight,speed,time

 Weight,speed,time

Weight,speed,time

Weight,speed,time,temperature

(r/min) Speed Range

0~1400

0~1400

0~1400

0~1400

Working plate material

Stainless steel

Stainless steel

Stainless steel

Aluminum Alloy

(mm) Dimension

410×300×130

515×400×155

650×500×900

650×500×900
