Compact Digital Magnetic Hotplate Stirrer – P8-2T / PT05-3T, Brushless DC Motor, Up to 150°C Liquid Temp

Speed Range: 0~1500(r/min)
Max.stirring capacity: 250ml or 500ml / 1000ml (depend on models)
℃ Liquid temperature range: Room temperature-150
(min) Timing range: 250

Availability:
Quantity:
facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
sharethis sharing button
  • P8-2T / PT05-3T

  • TOP

Aluminum alloy die casting shell as a whole, brushless DC motor drive, variable speed. Using electric heating units with heated area is characterized by a uniform warming fast maximum temperature 380℃. A variety of models suitable for you requirements


Type

P8-2T

PT05-3T

Control

Button

Button

(AC) Voltage

220V

220V

Max.stirring capacity

250ml or 500ml

1000ml

Motor type

Brushless DC Motor

BrushlessDC Motor

Motor Power

10W

15W

(r/min) Speed Range

0~1500

0~1500

Digital Display

Speed temperature time

Speed temperature time

(W)  Heating power

160W/260W

380W

Liquid temperature range

Room temperature-150

Room temperature-150

(℃)

Extermal temperature temperature control precision

±1

±1

(min) Timing range

250

250

(mm) Dimension

250×150×170

315×190×190

(kg) Weight

4.5

6.5
