90-1/90-1A/90-1B/96-1/P01-2
TOP
Brushless DC motor drive,variable speed.Stainless steel working face Strong magneticforce Structure is strong enough to withstand ten weight of the maximum stirring capacity The company's self-produced special speed range can be customized.
Type | 90-1 | 90-1A | 90-1B | 96-1 | P01-2 |
Control | Knob | Knob | Knob | Knob | Knob |
( AC ) Voltage | 220V | 220V | 220V | 220V | 220V |
Max.stirring capacity | 20L | 20L | 20L | 50L | 50L |
Motor type | Brushless DC Motor | Brushless DC Motor | Brushless DC Motor | Brushless DC Motor | Brushless DC Motor |
Motor Power | 40W | 40W | 40W | 100W | 100W |
Digital Display | 一 | Voltmeter shows the outputvoltage | Speed | 一 | Speed |
(r/min) Speed Range | 0~2000 | 0~2000 | 0~2000 | 0~1400 | 0~1400 |
Working platematerial | Stainless steel | Stainless steel | Stainless steel | Stainless steel | Stainlesssteel |
(mm) Dimension | 305×300×105 | 305×300×105 | 305×300×105 | 410×400×115 | 410×400×115 |
(kg) Weight | 8.6 | 8.6 | 8.6 | 12.2 | 12.2 |
Note:The output voltage is adjustable for a 220V socket equipped with 90-1A magnetic stirrer.Coupled with heating pipes and conductive thermometers,Temperature control is available for it.
