5L & 10L Brushless DC Motor Hotplate Stirrers with Digital Speed, Temperature & Timer Control, 360W-800W Heating, Precise Temperature up to 250°C

You are here: home » Products » Hotplates & Stirrers » Hotplate Stirrers (Combination) » 5L & 10L Brushless DC Motor Hotplate Stirrers with Digital Speed, Temperature & Timer Control, 360W-800W Heating, Precise Temperature up to 250°C

Product Category

5L & 10L Brushless DC Motor Hotplate Stirrers with Digital Speed, Temperature & Timer Control, 360W-800W Heating, Precise Temperature up to 250°C

Motor Type: Brushless DC motor with microprocessor control
Max Stirring Capacity: 5L / 10L / 10L
Speed Range: 0–1500 rpm
Heating Power: 360W / 800W stainless steel heating plate
Liquid Temperature Range: Room temperature to 150°C or 250°C
Temperature Control Precision: ±1°C
Timing Range: Up to 250 minutes
Working Plate Size: φ145 mm / φ175 mm

Quantity:
Availability:





Inquire Add to Basket

Model:
P01-1G / P01-1A / PT05-3G
Brand:
TOP

Brushless DC motor drive, Microprocessor control, A variety of models suitable for you requirements.

Digital Thermostat Magnetic Stirrer Magnetic Stirrer with Thermostat and Timer High Temperature Magnetic Stirrer Industrial Magnetic Stirrer with Temperature Control Magnetic Stirrer Hotplate with Thermostat

Related Products

LCD Digital Hotplate Magnetic Stirrer with Timer P-H-ProT

P-H-ProT Magnetic Hotplate Stirrer with LCD Display, Timer, PT1000 Sensor, and RS232 Data Interface

LCD Digital Hotplate Magnetic Stirrer P7-H550-PRO

P7-H550-PRO Magnetic Hotplate Stirrer – LCD Display, PID Control, 20L Capacity, 550°C Heating

LCD Digital Hotplate Magnetic Stirrer P-H-PRO+

P-H-PRO+ Digital Magnetic Hotplate Stirrer with LCD Display, PT1000 Sensor, and RS232 Data Interface for Laboratory Use

LED Digital Magnetic Hotplate Stirrer P7-H550-S

P7-H550-S Magnetic Hotplate Stirrer – LED Display, 10L Capacity, 550°C Heating with PT1000 Sensor

LED Digital Magnetic Hotplate Stirrer with Ceramic Plate P-H280-PRO

P-H280-PRO Magnetic Hotplate Stirrer – Digital Display, 10L Capacity, 550°C Heating for Laboratory Use

Type	P01-1G	P01-1A	PT05-3G
Control	Button	Button	Button
(AC) Voltage	220V	220V	220V
Max.stirring capacity	5L	10L	10L
Motor type	Brushless DC Motor	Brushless DC Motor	Brushless DC Motor
Motor Power	10W	15W	15W
(r/min) Speed Range	0~1500	0~1500	0~1500
Digital Display	Speed temperature time	Speed temperature time	Speed temperature time
Working plate material	Stainless steel	Stainless steel	Stainless steel
(mm) Working plate size	φ145	φ175	φ175
(W) Heating power	360W	800W	800W
℃Liquid temperature range	Room temperature-150	Room temperature-250	Room temperature-250
(℃)Extemal temperature control precision	±1	±1	±1
(min) Timing range	250	250	250
(mm ) Dimension	220×170×130	280×175×145	330×190×130
(kg) Weight	3.5	6.0	6.0

Type	P01-1G	P01-1A	PT05-3G
Control	Button	Button	Button
(AC) Voltage	220V	220V	220V
Max.stirring capacity	5L	10L	10L
Motor type	Brushless DC Motor	Brushless DC Motor	Brushless DC Motor
Motor Power	10W	15W	15W
(r/min) Speed Range	0~1500	0~1500	0~1500
Digital Display	Speed temperature time	Speed temperature time	Speed temperature time
Working plate material	Stainless steel	Stainless steel	Stainless steel
(mm) Working plate size	φ145	φ175	φ175
(W) Heating power	360W	800W	800W
℃Liquid temperature range	Room temperature-150	Room temperature-250	Room temperature-250
(℃)Extemal temperature control precision	±1	±1	±1
(min) Timing range	250	250	250
(mm ) Dimension	220×170×130	280×175×145	330×190×130
(kg) Weight	3.5	6.0	6.0
