Lightweight Handheld Homogenizer
You are here: home » Products » Rheometers & Viscometers » Homogenizer » Lightweight Handheld Homogenizer

Product Category


Lightweight Handheld Homogenizer

Model: PD-160

TOP INSTRUMENT Lightweight Handheld Homogenizer is designed for rapidly homogenize, emulsify, suspend and disrupt biological samples like tissue of animal, bacteria, yeast, plant samples, etc. in liquids. Ideal for samples from 0.1mL to 250mL depending on shaft chosen.
facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
sharethis sharing button
  • PD-160

  • TOP

Characteristic of Lightweight Handheld Homogenizer:

Unveiling the Lightweight Handheld Homogenizer with Ergonomic Design, the pinnacle of portable homogenization excellence. Crafted with precision and innovation, this handheld marvel is engineered to streamline manual operations with unparalleled efficiency and comfort.

  • Portable & Lightweight Design

Experience unmatched convenience with a compact, lightweight build and ergonomic design, making it perfect for manual operations on the go. Say goodbye to bulky equipment and hello to effortless homogenization wherever you need it.

  • Versatile Processing

With the ability to handle processing volumes ranging from 0.1 to 50 mL or 1 to 250 mL, this homogenizer offers versatility to suit a wide range of applications, from small-scale experiments to larger industrial processes.

  • Variable Speed Control

Harness the power of precision with variable speed control, allowing you to adjust the homogenization speed seamlessly from 8,000 to 32,000 rpm. Whether you require gentle mixing or high-speed homogenization, achieve optimal results with ease.

  • Autoclavable Stainless Steel Shafts

Our 316L stainless steel shafts are fully autoclavable, ensuring maximum hygiene and sterilization between uses. Experience peace of mind knowing that your equipment meets the highest standards of cleanliness and safety.

  • Interchangeable Shafts

Enjoy hassle-free maintenance and cleaning with interchangeable shafts, allowing for easy dismantling and thorough cleaning. Effortlessly switch between shafts to accommodate different sample types and applications, optimizing efficiency and versatility.

From its portable convenience to its precision performance, every aspect is meticulously crafted to elevate your workflow to new heights.

Speed range8000-32000rpm
Max linear velocity6.3m/sec or 14m/sec
Speed level10 stage
Working volume [H2O]0.1-50mL (Dispersing shaft DS-160/5)
1-250mL (Dispersing shaft DS-160/10)
Max. viscosity5,000mPas
Material of Dispersing ShaftSS 316L stainless steel, PTFE
Noise Level72 dB(A)
Protection classIP20
Voltage, Frequency



Motor TypeAC carbon brush motor
Dimension [W*D*H]45mm*55mm*190mm
Permissible ambient temperature and humidity0-40℃, 85%RH

Accessories 第1页-1(1) 第1页-2(1) 第1页-3(1)
Volume 0.1-50mL 1-150mL 1-250mL
Max. Circum. Speed 6.3m/sec 10m/sec 14m/sec
Material 316L stainless steel
Application small amounts of  solid liquid mixed
Function dispersing tool for  solid/liquid media
