Automatic Sulfur Dioxide Analyzer

Model: ZDDN-9830S

TOP INSTRUMENT Automatic Sulfur Dioxide Analyzer is a sulfur dioxide measuring instrument designed based on the principle of distillation according to national standards. It can automatically complete reagent addition, distillation, nitrogen blowing and other functions. This product is widely used in basic analysis, technological research and development, quality control and other fields.
facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
sharethis sharing button
  • ZDDN-9830S

  • TOP


  • The operating system adopts a 7-inch color touch screen, and the human-machine dialogue operation is simple and easy to learn.

  • Level 3 authority management and system parameter query comply with relevant certification requirements.

  • Automatically add required reagents, automatically distill, and automatically stop distillation and separation.

  • The nitrogen flow adjustment is at the front to facilitate user adjustment and use.

  • Professional and excellent pumps, valves, and acid- and alkali-resistant pipelines ensure product reliability and stability.

  • The system automatically shuts down after 60 minutes of unattended operation, which is energy-saving, safe and secure.

  • Distillation time can be set freely from 10 seconds to 9990 seconds.

  • The steam system is made of 304 stainless steel, which is safe and reliable.

  • The cooler system is made of 304 stainless steel, which has fast cooling speed and stable analysis data.

  • The 5mm thick transparent safety door and safety door alarm system ensure personal safety.

  • The leakage protection system ensures operator safety.

  • The test tube absence protection prevents injuries caused by adding reagents or heating the system.

  • Safety door protection settings ensure the personal safety of operators.

  • The water shortage protection of the steam system can automatically shut down and alarm to prevent accidents.

  • The steam pot over-temperature protection system can prevent the temperature in the steam pot from being too high and damaging the instrument.

Analysis scope0.1—50 mg
Nitrogen flow60—600ml/min
Nitrogen pressure≤ 0.1Mpa
Sample weightSolid ≤ 10g, liquid 20ml
Operating VoltageAC220V/50Hz
Distillation time0-9990 free setting
Heating power2000W
Sample analysis time5--10min/(cooling water temperature 18℃)
Titrant concentration range60 minutes
Net weight26Kg
