Handheld Homogenizer

Model: PD-160

TOP INSTRUMENT Handheld Homogenizer is designed for rapidly homogenize, emulsify, suspend and disrupt biological samples like tissue of animal, bacteria, yeast, plant samples, etc. in liquids. Ideal for samples from 0.1mL to 250mL depending on shaft chosen.

Quantity:
Availability:





Inquire Add to Basket

Model:
PD-160
Brand:
TOP

Characteristic:

Portable, lightweight with ergonomic design ideal for manual operations
Processing volumes from 0.1-50 mL or 1-250mL
Variable speed from 8,000 to 32,000 rpm
316L stainless steel shafts are fully autoclavable
Interchangeable shafts for easy dismantling and cleaning

Chemical Industrial Homogenizer Machine Mini Handheld High Shear Homogenizer Mixer High Precision Hand-held Tissue Homogenizer Handheld Homogenizer Portable Emulsifier Disperser Mixer Handheld Homogenizer Cell Stirrer Emulsifier With Handling Viscosity Handheld High Speed Disperse Homogenizer

Speed range	8000-32000rpm
Max linear velocity	6.3m/sec or 14m/sec
Speed level	10 stage
Working volume [H₂O]	0.1-50mL (Dispersing shaft DS-160/5)
Working volume [H₂O]	1-250mL (Dispersing shaft DS-160/10)
Max. viscosity	5,000mPas
Material of Dispersing Shaft	SS 316L stainless steel, PTFE
Noise Level	72 dB(A)
Protection class	IP20
Voltage, Frequency	110-120V/60Hz 220-240V/50-60Hz
Power	160W
Motor Type	AC carbon brush motor
Dimension [WDH]	45mm55mm190mm
Weight	0.54kg
Permissible ambient temperature and humidity	0-40℃, 85%RH

Speed range	8000-32000rpm
Max linear velocity	6.3m/sec or 14m/sec
Speed level	10 stage
Working volume [H₂O]	0.1-50mL (Dispersing shaft DS-160/5)
Working volume [H₂O]	1-250mL (Dispersing shaft DS-160/10)
Max. viscosity	5,000mPas
Material of Dispersing Shaft	SS 316L stainless steel, PTFE
Noise Level	72 dB(A)
Protection class	IP20
Voltage, Frequency	110-120V/60Hz 220-240V/50-60Hz
Power	160W
Motor Type	AC carbon brush motor
Dimension [WDH]	45mm55mm190mm
Weight	0.54kg
Permissible ambient temperature and humidity	0-40℃, 85%RH

Accessories
Volume	0.1-50mL	1-150mL	1-250mL
Max. Circum. Speed	6.3m/sec	10m/sec	14m/sec
Material	316L stainless steel
Application	small amounts of solid liquid mixed
Function	dispersing tool for solid/liquid media

Accessories
Volume	0.1-50mL	1-150mL	1-250mL
Max. Circum. Speed	6.3m/sec	10m/sec	14m/sec
Material	316L stainless steel
Application	small amounts of solid liquid mixed
Function	dispersing tool for solid/liquid media
