Characteristic:
Long service life Peltier heating units.
Highly performance universal powersupply.
Large 5.7 inch high-definition LCD display.
Graphical user interface in English and Chinese.
Power-down data protection.
Metal shell, solid, practical, beautiful and generous.
Stepless adjustable hot lid.
Lid can be positioned at any angle.
High-sealing reaction zone, to ensure stable and reliable test.
Characteristic:
Long service life Peltier heating units.
Highly performance universal powersupply.
Large 5.7 inch high-definition LCD display.
Graphical user interface in English and Chinese.
Power-down data protection.
Metal shell, solid, practical, beautiful and generous.
Stepless adjustable hot lid.
Lid can be positioned at any angle.
High-sealing reaction zone, to ensure stable and reliable test.
Model No. | TGT9612 | TGT9632 | TGT6022 |
Capacity | 96*0.2ml | 96*0.2ml+77*0.5ml | 60*0.5ml |
Temperature Range | 0-99℃ | 0-99℃ | 0-99℃ |
Heating Rate | 4.5°C/s | 4.5°C/s | 4.5°C/s |
Cooling Rate | 4°C/s | 4°C/s | 4°C/s |
Uniformity | <±0.3°C | <±0.3°C | <±0.3°C |
Accuracy | <±o.zc | <±o.zc | <±o.zc |
Display Resolution | 0.1°C | 0.1°C | 0.1°C |
Temperature Control | Block\Tube | Block\Tube | Block\Tube |
Ramping Rate Adjustable | 0.1-4.5°C | 0.1-4.5°C | 0.1-4.5°C |
Gradient Uniformity | <±0.3°C | <±0.3°C | <±0.3°C |
Gradient Accuracy | <±0.2°C | <±0.2°C | <±0.2°C |
Gradient Temp. Range | 30-99.9PC | 30-99.9PC | 30-99.9PC |
Gradient Spread | 1-30°C | 1-30°C | 1-30°C |
Hot Lid Temperature | 30-110°C | 30-110°C | 30-110°C |
Hot Lid Height Adjustable | Stepless Adjustable | Stepless Adjustable | Stepless Adjustable |
Number of Programs | 200 | 200 | 200 |
Max.No.of Segment | 9 | 9 | 9 |
Max.No.of Step | 9 | 9 | 9 |
Max.No.of Cycle | 99 | 99 | 99 |
Time Increment/Decrement | 1 Sec-9 Min 59 Sec | 1 Sec-9 Min 59 Sec | 1 Sec-9 Min 59 Sec |
Temp. Increment/Decrement | 0.1-9.9°C | 0.1-9.9°C | 0.1-9.9°C |
Pause Function | Yes | Yes | Yes |
Auto Data Protection | Yes | Yes | Yes |
Graphical Display | Yes | Yes | Yes |
Hold at 4°C | Forever | Forever | Forever |
Touchdown Function | Yes | Yes | Yes |
Long PCR Function | Yes | Yes | Yes |
Language | English | English | English |
LCD | 5.7inch, 320*240 pels | 5.7inch, 320*240 pels | 5.7inch, 320*240 pels |
Dimensions | 392mm*262mm*252mm (L*W*H) | 392mm*262mm*252mm (L*W*H) | 392mm*262mm*252mm (L*W*H) |
Weight | 10kg | 10kg | 10kg |
Power Supply | 85-264VAC, 50-60Hz, 600W | 85-264VAC, 50-60Hz, 600W | 85-264VAC, 50-60Hz, 600W |
Model No. | TGT9612 | TGT9632 | TGT6022 |
Capacity | 96*0.2ml | 96*0.2ml+77*0.5ml | 60*0.5ml |
Temperature Range | 0-99℃ | 0-99℃ | 0-99℃ |
Heating Rate | 4.5°C/s | 4.5°C/s | 4.5°C/s |
Cooling Rate | 4°C/s | 4°C/s | 4°C/s |
Uniformity | <±0.3°C | <±0.3°C | <±0.3°C |
Accuracy | <±o.zc | <±o.zc | <±o.zc |
Display Resolution | 0.1°C | 0.1°C | 0.1°C |
Temperature Control | Block\Tube | Block\Tube | Block\Tube |
Ramping Rate Adjustable | 0.1-4.5°C | 0.1-4.5°C | 0.1-4.5°C |
Gradient Uniformity | <±0.3°C | <±0.3°C | <±0.3°C |
Gradient Accuracy | <±0.2°C | <±0.2°C | <±0.2°C |
Gradient Temp. Range | 30-99.9PC | 30-99.9PC | 30-99.9PC |
Gradient Spread | 1-30°C | 1-30°C | 1-30°C |
Hot Lid Temperature | 30-110°C | 30-110°C | 30-110°C |
Hot Lid Height Adjustable | Stepless Adjustable | Stepless Adjustable | Stepless Adjustable |
Number of Programs | 200 | 200 | 200 |
Max.No.of Segment | 9 | 9 | 9 |
Max.No.of Step | 9 | 9 | 9 |
Max.No.of Cycle | 99 | 99 | 99 |
Time Increment/Decrement | 1 Sec-9 Min 59 Sec | 1 Sec-9 Min 59 Sec | 1 Sec-9 Min 59 Sec |
Temp. Increment/Decrement | 0.1-9.9°C | 0.1-9.9°C | 0.1-9.9°C |
Pause Function | Yes | Yes | Yes |
Auto Data Protection | Yes | Yes | Yes |
Graphical Display | Yes | Yes | Yes |
Hold at 4°C | Forever | Forever | Forever |
Touchdown Function | Yes | Yes | Yes |
Long PCR Function | Yes | Yes | Yes |
Language | English | English | English |
LCD | 5.7inch, 320*240 pels | 5.7inch, 320*240 pels | 5.7inch, 320*240 pels |
Dimensions | 392mm*262mm*252mm (L*W*H) | 392mm*262mm*252mm (L*W*H) | 392mm*262mm*252mm (L*W*H) |
Weight | 10kg | 10kg | 10kg |
Power Supply | 85-264VAC, 50-60Hz, 600W | 85-264VAC, 50-60Hz, 600W | 85-264VAC, 50-60Hz, 600W |
